• Module Output Data
SI unit (EX600-SEC )
Index
70x0:0 Slot x: Valve Outputs
70x0:01 Channel 0
• • • • • •
∗: x: Slot No.
Digital output unit (EX600-DY
Index
70x0:0 Slot x: Digital Outputs
70x0:01 Channel 0
• • • • • •
∗: x: Slot No.
Analogue output unit (EX600-AYA or EX600-AMB)
Index
70x0:0 Slot x: Analog Outputs
70x0:01 Channel 0
70x0:02 Channel 1
∗: x: Slot No.
Table. Module Output Data (SI)
Name / Meaning
or EX600-DM )
Table. Module Output Data (DY or DM)
Name / Meaning
Table. Module Output Data (AY or AM)
Name / Meaning
-77-
Type Flags
USINT RO
BOOL RO P
• • • • • •
Type Flags
USINT RO
BOOL RO P
• • • • • •
Type Flags
USINT RO
UINT RO P
UINT RO P
Value
Number of
channels
FALSE (OFF)
TRUE (ON)
• • •
Value
Number of
channels
FALSE (OFF)
TRUE (ON)
• • •
Value
Number of
channels
0 to 65535
0 to 65535
