•Analogue output unit parameters (2)
Parameter
No.
(H.T. Symbol)
Output setting
Set output per
for
channel during
7 communication
communication
∗ 4
idling
idling.
(Idle_MA)
∗1: When "Scaled" is selected as the analogue data format, the display of H.T. is switched from Upr_Lmt to UpLm/Scl, from Lwr_Lmt to
LwLm/Scl.
∗2: Set value shall be set per analogue input range within settable range in the table below.
When the analogue input range is changed, check the set value and change it to an appropriate value.
∗3: For settings of the user upper/lower limit or scale upper/lower limit via EtherCAT, make sure to set the upper limit set value larger than
the lower limit set value, as the setting is actually invalid if it is set with the upper limit set value is smaller than the lower limit set value,
although the setting in such condition is be set to be "valid".
∗4: This master is valid only when "Hold/Clear priority" of the system parameter is set to Handheld.
Analogue output
measurement range
(Range)
0..10 V
0..5 V
1..5 V
0..20 mA
4..20 mA
Definition Item
Enable
Disable
Upper and lower setting limit of user setting
(Lwr_Lmt)
0.00 to +10.45 V
0.00 to + 5.22 V
+0.75 to +5.22 V
0.00 to +20.90 mA
+3.00 to +20.90 mA
Content
Output will be user idle
∗ 2
value.
Output will be held last
state.
communication error or idling
(Upr_Lmt)
+0.05 to +10.50 V
+0.03 to +5.25 V
+0.78 to +5.25 V
+0.10 to +21.00 mA
+3.10 to +21.00 mA
-50-
Parameter
setting
Default
By
setting
Ether
CAT
○
○
Settable range during
(Fault_MA) (Idle_MA)
0.00 to +10.50 V
0.00 to +5.25 V
+0.75 to +5.25 V
0.00 to +21.00 mA
+3.00 to +21.00 mA
