•Module Output Data (Device specific object)
Index
7000:0 (No output data allocation)
Digital Outputs / DY(B
7010:0
7010:01 Channel 0
• • • • • •
7010:08 Channel 7
7020:0 Digital Outputs / DM(E
7020:01 Channel 0
• • • • • •
7020:08 Channel 7
7030:0
(No output data allocation)
7040:0 Analog Outputs / AYA
7040:01 Channel 0
7040:02 Channel 1
7050:0 Analog Outputs / AMB
7050:01 Channel 2
7050:02 Channel 3
7060:0 Valve Outputs / SI unit
7060:01 Channel 0
• • • • • •
7060:10 Channel 15
70A0:0 (No output data allocation)
Table. Module Output Data composition example
Name / Meaning
-70-
Slot No.
Slot 0
Slot 1
Slot 2
Slot 3
Slot 4
Slot 5
Slot 6
Diag.
No.EX##-OMO0027
