SMC Networks EX600-SEC Series Operation Manual page 94

Analogue input unit (EX600-AXA), Analogue output unit (EX600-AＹA)
Index
90x0:0 Slot x: Module identification
90x0:01 Address of the module
90x0:09 Module PDO group
90x0:0A Module ident
90x1:0 Slot x: Short circuit
90x1:01 Channel 0
90x1:02 Channel 1
∗ 1
90x2:0 Slot x: Over range
∗ 1
90x2:01 Channel 0
∗ 1
90x2:02 Channel 1
∗ 1
90x3:0 Slot x: Under range
∗ 1
90x3:01 Channel 0
∗ 1
90x3:02 Channel 1
90x4:0 Slot x: Over upper limit value
90x4:01 Channel 0
90x4:02 Channel 1
90x5:0 Slot x: Under lower limit value
90x5:01 Channel 0
90x5:02 Channel 1
∗: x: Slot No.
∗1: Applicable to the analogue input unit.
Table. Information Data (AX, AY)
Name / Meaning
-93-
Type
USINT 10
UINT Slot No.
UINT 1
32 (AX)
DINT
34 (AY)
USINT 2
FALSE (Undetected)
BOOL
TRUE (Detected)
FALSE (Undetected)
BOOL
TRUE (Detected)
USINT 2
FALSE (Undetected)
BOOL
TRUE (Detected)
FALSE (Undetected)
BOOL
TRUE (Detected)
USINT 2
FALSE (Undetected)
BOOL
TRUE (Detected)
FALSE (Undetected)
BOOL
TRUE (Detected)
USINT 2
FALSE (Undetected)
BOOL
TRUE (Detected)
FALSE (Undetected)
BOOL
TRUE (Detected)
USINT 2
FALSE (Undetected)
BOOL
TRUE (Detected)
FALSE (Undetected)
BOOL
TRUE (Detected)
Value
