Analogue output unit (EX600-AYA)
Index
80x0:0 Slot x: Module identification
80x0:01 Address of the module
80x0:09 Module PDO group
80x0:0A Module ident
80x1:0 Slot x: Unit Parameters
80x1:01 Monitor short circuit (in)
80x1:0D Data format
80x2:0 Slot x: Fault mode
Channel 0 /
80x2:01
Output setting during communication fault
Channel 1 /
80x2:02
Output setting during communication fault
80x3:0 Slot x: Fault value
Channel 0 /
80x3:01
Output setting value during communication fault
Channel 1 /
80x3:02
Output setting value during communication fault
80x4:0 Slot x: Idle mode
Channel 0 /
80x4:01
Output setting during communication idling
Channel 1 /
80x4:02
Output setting during communication idling
80x5:0 Slot x: Idle value
Channel 0 /
80x5:01
Output setting value during communication idling
Channel 1 /
80x5:02
Output setting value during communication idling
80x6:0 Slot x: Monitor upper limit
80x6:01 Channel 0 / Monitor user set upper limit
80x6:02 Channel 1 / Monitor user set upper limit
80x7:0 Slot x: Upper limit value
80x7:01 Channel 0 / User set upper limit value
80x7:02 Channel 1 / User set upper limit value
Table. Configuration Data (AY)
Name / Meaning
-84-
Type
USINT 10
UINT Slot No.
UINT 1
DINT 34
USINT 13
0=Disable
Enum0807
1=Enable
0=Offset binary
1=Sign & Magnitude
Enum0802
2=2's complement
3=Scaled
USINT 2
0=Disable (Hold)
Enum0807
1=Enable (Fault value)
USINT 2
UINT 0 to 65535
USINT 2
0=Disable (Hold)
Enum0807
1=Enable (Fault value)
USINT 2
UINT 0 to 65535
USINT 2
0=Disable
Enum0807
1=Enable
USINT 2
UINT 0 to 65535
Value
