SMC Networks EX600-SEC Series Operation Manual page 63

I/O Map
Each unit of the product has its own I/O occupied byte.
Unit
SI unit
Digital input unit
Digital output unit
Digital I/O unit
Analogue input unit
Analogue output unit
Analogue I/O unit
Unit part number
EX600-SEC
(32 outputs)
EX600-SEC
(24 outputs)
EX600-SEC
(16 outputs)
EX600-SEC
(8 outputs)
EX600-DX B
(8 inputs)
EX600-DX C
(8 inputs)
EX600-DX C1
(8 inputs)(with open circuit detection)
EX600-DX D
(16 inputs)
EX600-DX E
(16 inputs)
EX600-DX F
(16 inputs)
EX600-DY B
(8 outputs)
EX600-DY E
(16 outputs)
EX600-DY F
(16 outputs)
EX600-DM E
(8 inputs/8 outputs)
EX600-DM F
(8 inputs/8 outputs)
EX600-AXA
(2 channels)
EX600-AYA
(2 channels)
EX600-AMB
(2/2 channels)
Input
0
0
0
0
1
1
1
2
2
2
0
0
0
1
1
4
(2 byte/1 channel)
0
4
(2 byte/1 channel)
-62-
Occupied byte
Output
4
3
2
1
0
0
0
0
0
0
1
2
2
1
1
0
4
(2 byte/1 channel)
4
(2 byte/1 channel)
No.EX##-OMO0027
