Digital I/O unit (EX600-DM
Index
80x0:0 Slot x: Module identification
80x0:01 Address of the module
80x0:09 Module PDO group
80x0:0A Module ident
80x1:0 Slot x: Unit Parameters
80x1:01 Monitor short circuit (in)
80x1:02 Monitor short circuit (out)
80x1:05 Inrush current filter
80x1:06 Restart after short circuit
80x1:09 Digital input filtering time
80x1:0B Digital input extension time
80x2:0 Slot x: Fault mode
Channel 0 (Out) /
80x2:01
Output setting during communication fault
• • • • • •
80x3:0 Slot x: Fault value
Channel 0 (Out) /
80x3:01
Output setting value during communication fault
• • • • • •
80x4:0 Slot x: Idle mode
Channel 0 (Out) /
80x4:01
Output setting during communication idling
• • • • • •
80x5:0 Slot x: Idle value
Channel 0 (Out) /
80x5:01
Output setting value during communication idling
• • • • • •
80x6:0 Slot x: Monitor count
Channel 0 (In) /
80x6:01
ON-OFF count upper limit detection
• • • • • •
)
Table. Configuration Data (DM)
Name / Meaning
-81-
Type
USINT 10
UINT Slot No.
UINT 2
DINT Unit ID
USINT 11
0=Disable
Enum0807
1=Enable
0=Disable
Enum0807
1=Enable
0=Disable
Enum0807
1=Enable
0=Manual
Enum0808
1=Auto
0=0.1 ms
1=1 ms
Enum0800
2=10 ms
3=20 ms
0=1 ms
1=15 ms
Enum0801
2=100 ms
3=200 ms
USINT Number of output channels
0=Disable (Hold)
Enum0807
1=Enable (Clear or Force ON)
• • • • • •
USINT Number of output channels
0=Off (Clear)
Enum0809
1=On (Force ON)
• • • • • •
USINT Number of output channels
0=Disable (Hold)
Enum0807
1=Enable (Clear or Force ON)
• • • • • •
USINT Number of output channels
0=Off (Clear)
Enum0809
1=On (Force ON)
• • • • • •
USINT Number of all channels
0=Disable
Enum0807
1=Enable
• • • • • •
Value
