80x8:0 Slot x: Monitor open circuit
80x8:01 Channel 0 / Open circuit detection
• • • • • •
80xF:0 Slot x: System parameter
80xF:02 Hold/Clear
∗: x: Slot No.
Digital input unit (EX600-DX
Index
80x0:0 Slot x: Module identification
80x0:01 Address of the module
80x0:09 Module PDO group
80x0:0A Module ident
80x1:0 Slot x: Unit Parameters
80x1:01 Monitor short circuit (in)
80x1:05 Inrush current filter
80x1:09 Digital input filtering time
80x1:0B Digital input extension time
80x6:0 Slot x: Monitor count
80x6:01 Channel 0 / ON-OFF counter upper limit
• • • • • •
80x7:0 Slot x: Count Value (x1000)
80x7:01 Channel 0 / ON-OFF frequency upper limit
• • • • • •
∗ 1
80x8:0 Slot x: Monitor open circuit
∗ 1
80x8:01 Channel 0 / Open circuit detection
∗ 1
• • • • • •
∗: x: Slot No.
∗1: Applicable to the open detecting digital input unit (EX600-DXC1).
Table. Configuration Data (SI) (continued)
Name / Meaning
)
Table. Configuration Data (DX)
Name / Meaning
-79-
Type
USINT Number of channels
0=Disable
Enum0807
1=Enable
• • • • • •
USINT 2
0=Switch
Enum0806
1=H.T. or parameter
Type
USINT 10
UINT Slot No.
UINT 2
DINT Unit ID
USINT 11
0=Disable
Enum0807
1=Enable
0=Disable
Enum0807
1=Enable
0=0.1 ms
1=1 ms
Enum0800
2=10 ms
3=20 ms
0=1 ms
1=15 ms
Enum0801
2=100 ms
3=200 ms
USINT Number of channels
0=Disable
Enum0807
1=Enable
• • • • • •
USINT Number of channels
1 to 65000
UINT (Times diagnostic has been
detected=Set value x1000)
• • • • • •
USINT Number of channels
0=Disable
Enum0807
1=Enable
• • • • • •
Value
Value
