Digital input unit (EX600-DX
Index
90x0:0 Slot x: Module identification
90x0:01 Address of the module
90x0:09 Module PDO group
90x0:0A Module ident
90x1:0 Slot x: Short circuit
90x1:01 Channel 0
• • • • • •
90x2:0 Slot x: Over ON/OFF counter
90x2:01 Channel 0
• • • • • •
∗ 1
90x3:0 Slot x: Open circuit
∗ 1
90x3:01 Channel 0
∗ 1
• • • • • •
90x4:0 Slot x: Counter
90x4:01 Channel 0
• • • • • •
∗: x: Slot No.
∗1: Applicable to the open detecting digital input unit (EX600-DXC1) and digital output unit.
), Digital output unit (EX600-DY
Table. Information Data (DX, DY)
Name / Meaning
-91-
)
Type
USINT 10
UINT Slot No.
UINT 2
DINT Unit ID
USINT Number of channels
FALSE (Undetected)
BOOL
TRUE (Detected)
• • • • • •
USINT Number of channels
FALSE (Undetected)
BOOL
TRUE (Detected)
• • • • • •
USINT Number of channels
FALSE (Undetected)
BOOL
TRUE (Detected)
• • • • • •
USINT Number of channels
UDINT 0 to 4294967295
• • • • • •
Value
