•Diagnostic data
Index
60A0:0 Diag. data
60A0:01 Under lower limit value
60A0:02 Over upper limit value
60A0:03 Under range
60A0:04 Over range
60A0:05 Over ON/OFF counter
60A0:06 Open circuit
60A0:07 Short circuit (out)
60A0:08 Short circuit (in)
60A0:09 Pwr output is out of range
60A0:0A Pwr control is out of range
60A0:0C Unit disconnection
60A0:0D Connection error
60A0:0F Memory error
60A0:10 Parameter read/write error
60A0:19 Digital input unit
60A0:1A Digital output unit
60A0:1B Analog input unit
60A0:1C Analog output unit
60A0:1D SI unit
60A0:21 Slot 0
60A0:22 Slot 1
60A0:23 Slot 2
60A0:24 Slot 3
60A0:25 Slot 4
60A0:26 Slot 5
60A0:27 Slot 6
60A0:28 Slot 7
60A0:29 Slot 8
60A0:2A Slot 9
Table. Module Input Data (Diag.)
Name / Meaning
-76-
Type Flags
USINT RO
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
BOOL RO P
Value
29 or 42
FALSE
(Undetected)
TRUE (Detected)
