Page 1 Magellan™ 1500i Omni-Directional Imaging Scanner Product Reference Guide...
Page 2 Datalogic and the Datalogic logo are registered trademarks of Datalogic S.p.A. in many countries, including the U.S.A. and the E.U. Magellan is a trademark of Datalogic S.p.A. or of Datalogic and/or its affiliates, registered in many countries, including the U.S. and the E.U.
Page 3: Table Of Contents
Getting Started ..................................10 Programming Mode ................................10 Programming Session ................................11 If You Make a Mistake................................12 Return to Factory Settings .............................12 Datalogic Scanalyzer ................................13 Service Port Mode ..................................14 GENERAL SCANNER FEATURES ................................. 15 1D Double Read Timeout .................................16 2D Double Read Timeout .................................17 Double Read Table Size ..................................18...
Page 4 Good Read Beep Length .................................. 39 Good Read Beep Volume ................................. 40 Good Read When to Indicate ................................41 Illumination During Disable Mode ..............................42 Object Sense Control ..................................43 Reading Illumination Duration ............................... 44 Illumination Blank on Beep ................................45 Green Spot Duration Time ................................
Page 5 ACK NAK Enable ................................89 RS-232 ACK Character ..............................90 RS-232 NAK Character ..............................91 RS-232 Retry on ACK NAK Timeout ..........................92 RS-232 ACK NAK Timeout Value ............................93 RS-232 ACK NAK Retry Count ............................94 RS-232 ACK NAK Error Handling ...........................95 RS-232 Indicate Transmission Failure ...........................96 DATA EDITING.......................................
Page 6 EAN-8 Guard Substitution ..............................141 EAN-8/Jan-8 Both Guards Substitution ..........................142 EAN-8 Stitch Exact Label Halves ............................143 EAN-8 Stitch Unlike Label Halves ............................144 EAN-8 Minimum Segment Length ............................145 EAN-8 Decoding Levels ................................. 147 Other UPC/EAN Options ................................148 In-Store Printed Label Minimum Read ..........................
Page 7 Code 39 Require Margins ..............................197 Code 32 Italian Pharmacode ................................ 198 Code 32 Italian Pharmacode Enable ............................ 198 Code 32 Start Stop Character Transmission ........................199 Code 32 Check Character Transmission ..........................200 Code 128 ......................................201 Code 128 Enable ..................................201 Code 128 Transmit Function Characters ..........................
Page 8 Standard 2 of 5 Minimum Read ............................244 Standard 2 of 5 Correlation ..............................245 Standard 2 of 5 Length Control ............................246 Standard 2 of 5 Length 1 ..............................247 Standard 2 of 5 Length 2 ..............................248 2D SYMBOLOGIES/POSTAL CODES ..............................249 Data Matrix .....................................
Page 9 IMB ........................................280 IMB Enable ..................................... 280 Sweden Post ....................................281 Sweden Post Enable ................................281 Portugal Post ....................................282 Portugal Post Enable ................................282 Chapter 3. REFERENCES ..................................283 Global Prefix/Suffix ..................................283 Label ID ......................................284 Label ID ..................................285 Length Control ..................................
Page 10 NOTES viii Magellan™ 1500i...
Page 11: Chapter 1 Introduction
POS (Point of Sale). The Magellan 1500i uses intelligent illumination technology to optimize light levels for a variety of barcode scanner functions including automatic reading of barcodes from printed surfaces, mobile devices and image capture in variable contrast environments.
Page 12: Connecting The Scanner
Connecting the Scanner Connecting the Scanner The scanner kit you ordered to match your interface should provide a compati- ble cable for your installation. Alternatively, if your scanner receives Power Off the Terminal (POT) it might be possible to connect using a cable from a previ- ously existing installation (except for USB).
Page 13 Manual Conventions Figure 2. Scanner Features - Front View Good Read Light Pipe/ Scanner Button Beeper Grille Illumination LEDs Scan Window Tilting Stand Figure 3. Scanner Features - Bottom View Power/interface Cable Latch Release Hole Power/Interface Stand Product Reference Guide...
Page 14: Optional Stand/Riser
Connecting the Scanner Optional Stand/Riser An optional stand / riser is available for the scanner. The stand and riser have anti-skid pads on the bottom and can rest on any desired horizontal surface or countertop. The scanner (along with the stand/riser) can be easily repositioned on the counter or lifted for portable use.
Page 15: How To Scan
Handheld Scanning Mode How to Scan Barcodes can be presented to the scanner while it is resting on the counter, or the scanner can be picked up for targeted scanning. Figure 4. Scanning Methods PRESENTATION MODE HANDHELD MODE Scan Button/ Good Read Indicator Handheld Scanning Mode...
Page 16: Cleaning
CAUTION Manufacturer Approved Cleaning Materials Datalogic recommends the use of the following cleaners on its products. APPROVED CLEANERS •Hydrogen Peroxide (not to exceed a 3% solution) •Chlorine bleach (not to exceed a 0.25% solution) •Mild detergent and water...
Page 17: Do Not Use Abrasive Cleansers
Do Not Use Abrasive Cleansers! Do Not Use Abrasive Cleansers! Under no circumstances should abrasive cleansers, abrasive pads, caustic solu- tions or other harsh chemicals, including those listed below, be used on any part of the scanner as they can cause damage which will adversely affect scan- ning performance.
Page 18: Chapter 2. Programming
"Programming with Barcodes" on page 9 to get started. An additional programming option is to use Scanalyzer Configuration Utility — Datalogic’s Scanalyzer software configuration utility, available for free down- load from the Datalogic website. See "Datalogic Scanalyzer" on page 13 more information.
Page 19: Programming With Barcodes
Programming with Barcodes Programming with Barcodes If you have little or no prior experience with programming using barcode labels, you should review the next few pages of this section to familiarize yourself with the basics of scanner programming before performing any changes to your configuration.
Page 20: Getting Started
About Programming your Scanner Getting Started After scanning the interface barcode from the Interface Related Features sec- tion, you can select other options and customize your scanner through use of the instructions and programming barcodes available in that section and also Data Editing 1D Symbologies chapters of this manual.
Page 21: Programming Session
Programming Session Programming Session A typical programming session is conducted as follows: 1. Scan the Enter/Exit Programming Mode bar code to place the scanner in Programming Mode. Depending upon its current programming, the scan- ner may emit a beep or beeps, indicating it has read the bar code and the green LED will flash on and off slowly while the scanner remains in Pro- gramming Mode.
Page 22: If You Make A Mistake
About Programming your Scanner If You Make a Mistake... If, during a programming session, you find that you are unsure of the scanner’s settings or wish to reset the scanner’s configuration, use the Return to Factory Settings label below to return the scanner’s configuration to the factory set- tings.
Page 23: Datalogic Scanalyzer
NOTE The Datalogic Scanalyzer Configuration and Maintenance Tool (‘Scanalyzer tool’) is a Microsoft Windows®-based utility for current Datalogic Fixed Retail Products. The Scanalyzer tool has the ability to manage your Datalogic Fixed Retail Scanner, offering the following capabilities: • Create and print your own programming barcode labels for scanning.
Page 24: Service Port Mode
About Programming your Scanner Service Port Mode To program the Magellan 1500i using software utilities such as Scanalyzer or Aladdin, the unit must first be placed into Service Port mode. There are two methods that can be used to accomplish this. Hold the Scan Button 1.
Page 25: General Scanner Features
General Scanner Features CANNING EATURES starting on page 16 • 1D Double Read Timeout on page 16 • 2D Double Read Timeout on page 17 • Double Read Table Size on page 18 • Digital Watermark (Digimarc) Features on page 19 Digital Watermark (Digimarc) Enable on page 19 Digital Watermark (Digimarc) Double Read Timeout on page 20 Digital Watermark (Digimarc) Data Format on page 21...
Page 26: Double Read Timeout
Enter/Exit Programming Mode 1D Double Read Timeout SCANNING FEATURES 1D Double Read Timeout The 1D Double Read Timeout feature specifies the minimum allowable time which must pass before reading the same 1D label again (e.g. two identical items in succession). To set the Double Read Timeout: 1.
Page 27: Double Read Timeout
2D Double Read Timeout Enter/Exit Programming Mode 2D Double Read Timeout The 2D Double Read Timeout feature specifies the minimum allowable time which must pass before reading the same 2D label again (e.g. two identical items in succession). To set this feature: 1.
Page 28: Double Read Table Size
Enter/Exit Programming Mode Double Read Table Size Double Read Table Size Specifies the number of labels to be tracked if double read protection is needed. Contact Technical Support for more information. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 29: Digital Watermark (Digimarc) Features
Digital Watermark (Digimarc) Features Enter/Exit Programming Mode Digital Watermark (Digimarc) Features Digital Watermark (Digimarc) Enable Enables/Disables the ability of the scanner to decode Digital Watermarks. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 30: Digital Watermark (Digimarc) Double Read Timeout
Enter/Exit Programming Mode Digital Watermark (Digimarc) Features Digital Watermark (Digimarc) Double Read Timeout Specifies the minimum allowable time which must pass before reading the same Digital Watermark (Digimarc) label again (e.g. two identical items in suc- cession). To set this feature: 1.
Page 31: Digital Watermark (Digimarc) Data Format
Digital Watermark (Digimarc) Features Enter/Exit Programming Mode Digital Watermark (Digimarc) Data Format Selects the format for the watermark data. Choices are: • Compatibility mode • Databar-14 • Native 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 32: Inverse Read Control
Enter/Exit Programming Mode 1D Inverse Read Control 1D Inverse Read Control This configuration item is used to toggle inverted label reading for 1D bar- codes, for example, a label printed as white on black as opposed to black on white. To set this feature: 1.
Page 33: Inverse Read Control
2D Inverse Read Control Enter/Exit Programming Mode 2D Inverse Read Control This configuration item is used to toggle inverted label reading for 2D bar- codes, for example, a label printed as white on black as opposed to black on white. To set this feature: 1.
Page 34: Handheld State
Enter/Exit Programming Mode Handheld State Handheld State When enabled, places the scanner in Handheld State of operation. 150000(CR) DEFAULT Handheld State = Disable 150001(CR) Handheld State = Enable Magellan™ 1500i...
Page 35: Center Zone Enable
Center Zone Enable Enter/Exit Programming Mode Center Zone Enable Enables or Disables Center Zone Label Proofing. In "Always On" mode, Zone Proofing will be applied to labels presented to the scanner while in Active State and in HandHeld State. Labels rendered by segment assembly carry no coordinate data, and will not be proofed if Center Zone Label Proofing is enabled.
Page 36: Center Zone Size
Enter/Exit Programming Mode Center Zone Size Center Zone Size Specifies the Center Zone size as a percentage of the full image. 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan the barcode below. You’ll need to cover any Set Center Zone Size unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 37: Sleep Mode Timer
Sleep Mode Timer Enter/Exit Programming Mode Sleep Mode Timer This feature specifies the amount of time of inactivity (with no label reads) before the scanner enters sleep mode. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 38: Accelerometer Detect Threshold
Enter/Exit Programming Mode Accelerometer Detect Threshold Accelerometer Detect Threshold Sets acceleration threshold that must be exceeded for an InMotionEvent to be generated. Setting the Reject Threshold (page 29) to LOWEST while this feature is set to HIGHEST will result in the scanner rejecting all motion inputs.
Page 39: Accelerometer Reject Threshold
Accelerometer Reject Threshold Enter/Exit Programming Mode Accelerometer Reject Threshold Sets acceleration threshold above which data from the accelerometer will be rejected. Setting this feature to LOWEST while the Detect Threshold (page 28) is set to HIGHEST will result in the scanner rejecting all motion inputs.
Page 40: Accelerometer Delay To Stationary
Enter/Exit Programming Mode Accelerometer Delay To Stationary Accelerometer Delay To Stationary Sets amount of time the scanner will remain in Scanner Active Mode/Handheld State following the last valid detected motion. 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 41: Accelerometer Inmotion Threshold
Accelerometer Inmotion Threshold Enter/Exit Programming Mode Accelerometer Inmotion Threshold Sets acceleration threshold that must be exceeded once in ScannerActiveMode/ HandheldState for the device to remain in ScannerActiveMode/HandheldState. 150900(CR) Accelerometer Inmotion Threshold = Lowest 150901(CR) DEFAULT Accelerometer Inmotion Threshold = Low 150902(CR) Accelerometer Inmotion Threshold = Medium 150903(CR)
Page 42: Power On Alert
Enter/Exit Programming Mode Power On Alert LED AND BEEPER INDICATORS Power On Alert Disables or enables the indication that the scanner has finished all its power up tests and is now ready for operation (usually a single beep). This feature is configurable so the beep can be replaced with a .wav file.
Page 43: External Read Indicator (Eri)
External Read Indicator (ERI) Enter/Exit Programming Mode External Read Indicator (ERI) This feature is available only through use of a special cable. NOTE 00F900(CR) DEFAULT ERI Active State = Active Low 00F901(CR) ERI Active State = Active High Product Reference Guide...
Page 44: Eri Timeout
Enter/Exit Programming Mode ERI Timeout ERI Timeout Specifies the amount of time the External Read Indicator (ERI) signal is held active for a good read. Sets the ERI timeout duration using hex values from 000 to 255 in increments of ten milliseconds (10ms or 0.01 seconds). To configure this feature: 1.
Page 45: Good Read Led Idle State
Good Read LED Idle State Enter/Exit Programming Mode Good Read LED Idle State This feature specifies the state of the green scanner LEDs when the scanner is idle and ready to read a label. Options are: • • On dim To set the Scanner LEDs Idle State: 1.
Page 46: Scanner Control Button Options
Enter/Exit Programming Mode Scanner Control Button Options Scanner Control Button Options Configure the Scanner Control Button to one of the following modes of opera- tion: • Enable all functions: Volume, tone, diagnostics and reset. • Enable only volume, tone and reset. •...
Page 47: Good Read Beep Control
Good Read Beep Control Enter/Exit Programming Mode Good Read Beep Control This feature enables/disables scanner beep upon successfully decoding of a label. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 48: Good Read Beep Frequency
Enter/Exit Programming Mode Good Read Beep Frequency Good Read Beep Frequency Adjusts the scanner’s good read beep to sound at low, medium, or high fre- quency (controls the beeper’s pitch/tone). • • Medium • High To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 49: Good Read Beep Length
Good Read Beep Length Enter/Exit Programming Mode Good Read Beep Length Specifies the duration of a good read beep. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan the barcode, .
Page 50: Good Read Beep Volume
Enter/Exit Programming Mode Good Read Beep Volume Good Read Beep Volume Selects the beeper volume upon a good read beep. There are five selectable volumes, with each volume increment adding approximately five decibels to the previous level: • • Medium High •...
Page 51: Good Read When To Indicate
Good Read When to Indicate Enter/Exit Programming Mode Good Read When to Indicate This feature specifies when the scanner will provide indication (beep and/or flash its green LEDs) upon successfully reading a barcode. • Good Read = Indicate after decode. •...
Page 52: Illumination During Disable Mode
Enter/Exit Programming Mode Illumination During Disable Mode Illumination During Disable Mode This feature allows illumination to be turned off when the scanner is in “disable” mode. It determines if the imager illumination is controlled by host interface enable/disable commands. = Illumination is not controlled by host enable/disable commands, Disable illumination stays on when disabled.
Page 53: Object Sense Control
Object Sense Control Enter/Exit Programming Mode Object Sense Control This feature controls the illumination idle. It determines whether the main illu- mination is controlled by the Object Sensing system, or alternatively, stays con- tinuously on. = Illumination is controlled by using Object Sense Enable = Normal illumination is used but it goes off during sleep mode / Disable...
Page 54: Reading Illumination Duration
Enter/Exit Programming Mode Reading Illumination Duration Reading Illumination Duration This feature specifies how long the illumination stays on after a label or label segment is read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 55: Illumination Blank On Beep
Illumination Blank on Beep Enter/Exit Programming Mode Illumination Blank on Beep Enable this feature to turn off illumination while sound is playing. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. 3.
Page 56: Green Spot Duration Time
Enter/Exit Programming Mode Green Spot Duration Time Green Spot Duration Time This feature specifies the time that the Green Spot is active. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. 3.
Page 57: Imaging Features
Imaging Features MAGING EATURES starting on page 48 •Image Capture to the Host by Host Command on page 48 •Image Destination on page 49 •Picture Retrieval Timeout on page 50 •Image Capture Delay on page 52 •Image Format on page 53 •Image Size on page 54 •Image Brightness on page 55 •Image Contrast on page 57...
Page 58: Imaging Features
Imaging Features Imaging Features Image Capture to the Host by Host Command This feature is only available for RS-232 and USB COM interfaces. If the USB COM interface has been selected, follow the instruc- tions in USB Interface Selection on page 67. NOTE The host command format is as follows: P<cnt>pSBC...
Page 59: Image Destination
Imaging Features Enter/Exit Programming Mode Image Destination Specifies the destination for pictures/images taken with a camera button press. 042500(CR) DEFAULT Image Destination = Disable 042503\r Image Destination = Host port Product Reference Guide...
Page 60: Picture Retrieval Timeout
Enter/Exit Programming Mode Imaging Features Picture Retrieval Timeout This feature sets the amount of time after the picture retrieval label is sent to the POS that the scanner will allow subsequent picture taking requests via but- ton press. If set to 0, the picture retrieval timeout will not be used and a pic- ture will remain accessible until another is taken or the scanner is reset.
Page 61 Imaging Features Enter/Exit Programming Mode Picture Retrieval Timeout (continued) 042306(CR) Picture Retrieval Timeout = 6 seconds 042307(CR) Picture Retrieval Timeout = 7 seconds 042308(CR) Picture Retrieval Timeout = 8 seconds 042309(CR) Picture Retrieval Timeout = 9 seconds 04230A(CR) Picture Retrieval Timeout = 10 seconds Product Reference Guide...
Page 62: Image Capture Delay
Enter/Exit Programming Mode Imaging Features Image Capture Delay This feature specifies the amount of time after the image capture is initiated by a button press until the picture is taken. 042700(CR) Image Capture Delay = 0 seconds 042701(CR) Image Capture Delay = 1 second 042702(CR) Image Capture Delay = 2 seconds 042705(CR)
Page 63: Image Format
Imaging Features Enter/Exit Programming Mode Image Format This feature specifies the output format for images taken using the camera function of the scanner. Choices are: • • 03E900(CR) DEFAULT Image Format = JPG 03E901(CR) Image Format = BMP Product Reference Guide...
Page 64: Image Size
Enter/Exit Programming Mode Imaging Features Image Size This feature specifies the size of the captured image. Choices are: Video Graphics Array. 640 x 480 pixels. VGA — Wide Video Graphics Array, various physical sizes, 16:9 shape WVGA — Maximum image height and width. Largest image. Full Size —...
Page 65: Image Brightness
Imaging Features Enter/Exit Programming Mode Image Brightness Specifies the image brightness value. The selectable range is from 0 to 10, with 10 being the brightest. 03EB00(CR) DEFAULT Image Brightness = 0 03EB01(CR) Image Brightness = 1 03EB02(CR) Image Brightness = 2 03EB03(CR) Image Brightness = 3 03EB04(CR)
Page 66 Enter/Exit Programming Mode Imaging Features Image Brightness (continued) 03EB08(CR) Image Brightness = 8 03EB09(CR) Image Brightness = 9 03EB0A(CR) Image Brightness = 10 Magellan™ 1500i...
Page 67: Image Contrast
Imaging Features Enter/Exit Programming Mode Image Contrast This feature sets the contrast level for a captured image. The selectable range is from 0 to 10, with 0 being the lowest and 10 being the highest contrast. 03EC00(CR) DEFAULT Image Contrast = 0 03EC01(CR) Image Contrast = 1 03EC02(CR)
Page 68 Enter/Exit Programming Mode Imaging Features Image Contrast (continued) 03EC08(CR) Image Contrast = 8 03EC09(CR) Image Contrast = 9 03EC0A(CR) Image Contrast = 10 Magellan™ 1500i...
Page 69: Image Compression
Imaging Features Enter/Exit Programming Mode Image Compression Specifies the starting image compression factor. 03ED05(CR) Image Compression = 5 03ED0A(CR) Image Compression = 10 03ED19(CR) Image Compression = 25 03ED32(CR) Image Compression = 50 03ED46(CR) Image Compression = 70 03ED50(CR) Image Compression = 80 03ED5A(CR) Image Compression = 90 03ED64(CR)
Page 70: Region Of Interest (Roi)
Enter/Exit Programming Mode Imaging Features Region of Interest (ROI) This feature specifies the X-Y coordinates for the Region of Interest (ROI). The region of interest coordinates are defined as follows: Where xmax is the x-size of a full size image (1279 pixels), and ymax is the y-size of a full size image (1023 pixels).
Page 71 Imaging Features Enter/Exit Programming Mode Region of Interest (continued) 04EC000004FF000003FF(CR) DEFAULT Region of Interest = default 04EC0000028000000200(CR) Region of Interest = upper left quadrant 04EC028004FF00000200(CR) Region of Interest = upper right quadrant 04EC00000280020003FF(CR) Region of Interest = lower left quadrant 04EC028004FF020003FF(CR) Region of Interest = lower right quadrant Product Reference Guide...
Page 72: Number Of Imager Frames
Enter/Exit Programming Mode Imaging Features Number of Imager Frames This feature specifies the number of consecutive frames captured while using imager register values to toggle between Near Field and Far Field performance. This can be used when a greater depth of field is needed. •...
Page 73: Cell Phone Settings
Cell Phone Settings Enter/Exit Programming Mode Cell Phone Settings Cell Phone Mode Enables/disables the operating mode for mobile phone read. • In Toggle mode each host command toggles the mode. • In Timer Expiration mode, a single host command enters Cell Phone mode but it is exited at timer expiration.
Page 74: Cell Mode Percent
Enter/Exit Programming Mode Cell Phone Settings Cell Mode Percent Specifies the rate of frames dedicated to reading cell phones. Cell reading fea- ture must be enabled for this to be active. The setting reflects a variable setting (or percentage) of frames dedicated to cell reading As the percentage is increased, object sense (if enabled) will become less responsive.
Page 75: Interface Related Features
Interface Related Features starting on page 66 INTERFACE SELECTION USB Interface Selection on page 67 RS-232 Interface Selection on page 68 Maximum Host-Transmitted Message Length on page 69 starting on page 71 USB I NTERFACE EATURES USB-COM Interface Setup on page 71 •...
Page 76: Interface Type
Interface Type INTERFACE SELECTION Interface Type Specifies the current scanner interface. The correct interface cable is generally included for the reader interface type you ordered. NOTE If the scanner’s interface type must be changed, always be sure that interface configuration is the FIRST item scanned during a programming session.
Page 77: Usb Interface Selection
USB Interface Selection Enter/Exit Programming Mode USB Interface Selection Remember to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan. Great care should be taken to select the correct interface type, since you can cause damage to the scanner and/or POS termi- nal by attempting to change to an incompatible interface.
Page 78: Interface Selection
Enter/Exit Programming Mode RS-232 Interface Selection RS-232 Interface Selection This section lists the factory default settings for each of the menu commands for the standard RS-232 interface, indicated by a green arrow. Exceptions to default settings for other interfaces, including Wincor-Nixdorf, can be found in Appendix D, Factory Default Settings.
Page 79: Maximum Host-Transmitted Message Length
Maximum Host-Transmitted Message Length Enter/Exit Programming Mode INTERFACE FEATURES Maximum Host-Transmitted Message Length Specifies the maximum number of data characters allowed in messages trans- mitted to the host. To set the Maximum Host-Transmitted Message Length: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 80: Ignore Host Commands
Enter/Exit Programming Mode Ignore Host Commands Ignore Host Commands When set to ignore host commands, the scanner will ignore all host commands except the minimum set necessary to keep the interface active and transmit labels. For normal operation of the interface, select Obey Host Commands. 04F400(CR) DEFAULT Ignore Host Commands = Don’t Ignore...
Page 81: Usb Interface Features
Enter/Exit Programming Mode USB Interface Features USB-COM Interface Setup The Datalogic USB-COM driver is required to use USB-COM or USB-COM DL interfaces. The Datalogic USB-COM driver can be downloaded from the Data- logic website. Before plugging your scanner into the Host PC, please ensure you have already copied the executable DLS USB-COM driver file to your PC and that the scan- ner’s interface is set to USB COM or USB COM DL.
Page 82: Usb Keyboard Features
Enter/Exit Programming Mode USB Keyboard Features USB Keyboard Features As a keyboard interface, the scanner supports most popular PC terminals. Keyboard Layout The Keyboard Layout option supports many countries. For details about Key- board Layout, please refer to your operating system manual. USB Keyboard Country Mode This feature specifies the country/language that will be supported by the key- board.
Page 83 USB Keyboard Features Enter/Exit Programming Mode USB Keyboard Country Mode (continued) 030206(CR) USB Keyboard Country Mode = Italy 030207(CR) USB Keyboard Country Mode = Norway 030208(CR) USB Keyboard Country Mode = Portugal 030209(CR) USB Keyboard Country Mode = Spain 03020A(CR) USB Keyboard Country Mode = Sweden 03020B(CR)
Page 84 Enter/Exit Programming Mode USB Keyboard Features USB Keyboard Country Mode (continued) 03020D(CR) USB Keyboard Country Mode = Hungary 03020E(CR) USB Keyboard Country Mode = Czech Republic 03020F(CR) USB Keyboard Country Mode = Slovakia 030210(CR) USB Keyboard Country Mode = Romania 030211(CR) USB Keyboard Country Mode = Croatia 030212(CR)
Page 85: Usb Keyboard Caps Lock State
USB Keyboard Features Enter/Exit Programming Mode USB Keyboard Caps Lock State This feature specifies the format in which the scanner sends character data. Selections are: Send character data in normal format Caps Lock OFF — Send character data in reverse case Caps Lock ON —...
Page 86: Usb Keyboard Send Control Characters
Enter/Exit Programming Mode USB Keyboard Features USB Keyboard Send Control Characters This feature specifies how the scanner transmits ASCII control characters to the host. Affects suffix and prefix characters. When disabled, only ASCII characters between 20H and 127H inclusive (space... delete) plus special characters 0DH (carriage return), 08H (backspace), 27H (ESC), 09H (right tab) and 0BH (left tab) are transmitted.
Page 87: Usb Keyboard Intercharacter Delay
USB Keyboard Features Enter/Exit Programming Mode USB Keyboard Intercharacter Delay Specifies a time delay between characters. To set this feature: 1. Scan the Set USB Keyboard Intercharacter Delay barcode below. 2. Scan the appropriate characters/digits from the Alpha-Numeric Keypad in Appendix C that represent the desired delay.
Page 88: Usb Keyboard Additional Interface Options
Enter/Exit Programming Mode USB Keyboard Additional Interface Options USB Keyboard Additional Interface Options Appendix E, Keyboard Function Key Mappings for more information. To set this feature: 1. Scan the Enter/Exit Programming Mode bar code. 2. Scan your selection from the bar codes below. You’ll need to cover any unused bar codes on this and the facing page to ensure that the scanner reads only the bar code you intend to scan.
Page 89: Usb-Oem Features
USB-OEM Features Enter/Exit Programming Mode USB-OEM Features USB OEM Scanner Device Type The OEM-USB protocol allows for the scanner to be identified as one of two dif- ferent types of barcode scanners. Depending on what other scanners you may already have connected to a USB POS, you may need to change this setting to enable all scanners to communicate.
Page 90: Usb Oem Additional Interface Options
Enter/Exit Programming Mode USB OEM Additional Interface Options USB OEM Additional Interface Options To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 91: Interface Features
RS-232 Baud Rate Enter/Exit Programming Mode RS-232 Interface Features A setting of no parity with 7 data bits is invalid and will default to 8 data bits and no parity. NOTE RS-232 Baud Rate 001D04(CR) RS-232 Baud Rate = 1200 001D03(CR) RS-232 Baud Rate = 2400 001D02(CR)
Page 92 Enter/Exit Programming Mode RS-232 Baud Rate RS-232 Baud Rate (continued) 001D07(CR) RS-232 Baud Rate = 57600 001D08(CR) RS-232 Baud Rate = 115200 001D09(CR) RS-232 Baud Rate = 230400 Magellan™ 1500i...
Page 93: Number Of Data Bits
RS-232 Number of Data Bits Enter/Exit Programming Mode RS-232 Number of Data Bits Specifies number of data bits required for sending and receiving data. A setting of 7 data bits with no parity will default to 8 data bits and no parity. NOTE 009B00(CR) RS-232 Number of Data Bits = 7...
Page 94: Parity
Enter/Exit Programming Mode RS-232 Parity RS-232 Parity Specifies parity required for sending and receiving data. Options for this setting are: • RS-232 PARITY = NONE • RS-232 PARITY = EVEN • RS-232 PARITY = ODD A setting of no parity with 7 data bits will default to 8 data bits and no parity.
Page 95: Hardware Control
RS-232 Hardware Control Enter/Exit Programming Mode RS-232 Hardware Control Enables/disables use of the RS-232 CTS signal for flow control and/or scan control. Options are: • Disable — The scanner transmits to the host regardless of any activity on the CTS line. •...
Page 96: Intercharacter Delay
Enter/Exit Programming Mode RS-232 Intercharacter Delay RS-232 Intercharacter Delay Specifies delay between the end of one character and the beginning of the next in 10-millisecond increments. This delay is inserted after each data character transmitted. If the transmission speed is too high, the system may not be able to receive all characters.
Page 97: Software Flow Control
RS-232 Software Flow Control Enter/Exit Programming Mode RS-232 Software Flow Control Enables/disables RS-232 Flow Control using XON/ XOFF characters. This item will be ignored when the feature, RS-232 NAK Charac- ter, is enabled NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 98: Beep On Ascii Bel
Enter/Exit Programming Mode RS-232 Beep on ASCII BEL RS-232 Beep on ASCII BEL Enables/disables ability of scanner to beep (sound a good read tone) on receiv- ing an ASCII BEL (07 hex). 069D00(CR) DEFAULT RS-232 Beep on ASCII BEL = Disable 069D01(CR) RS-232 Beep on ASCII BEL = Enable Beep on Not on File...
Page 99: Ack Nak Features
RS-232 ACK NAK Features Enter/Exit Programming Mode RS-232 ACK NAK Features ACK NAK Enable This enables/disables the ability of the scanner to support the RS-232 ACK/ NAK protocol. When configured, the scanner and/or host sends an “ACK” when it receives data properly, and sends “NAK” when the data is in error. Selections for this option are: •...
Page 100: Ack Character
Enter/Exit Programming Mode RS-232 ACK NAK Features RS-232 ACK Character This feature specifies which ASCII character will be used as an ACK character. DO NOT set this feature to use previously defined char- acters such as XON, XOFF or host commands as this will conflict with normal operation of these characters.
Page 101: Nak Character
RS-232 ACK NAK Features Enter/Exit Programming Mode RS-232 NAK Character This feature specifies which ASCII character will be used as a NAK character. DO NOT set this feature to use previously defined char- acters such as XON, XOFF or host commands as this will conflict with normal operation of these characters.
Page 102: Retry On Ack Nak Timeout
Enter/Exit Programming Mode RS-232 ACK NAK Features RS-232 Retry on ACK NAK Timeout This option specifies the action scanner performs on expiration of the RS-232 ACK NAK Timeout Value. 032100(CR) RS-232 Retry on ACK NAK Timeout = Disable 032101(CR) DEFAULT RS-232 Retry on ACK NAK Timeout = Enable Magellan™...
Page 103: Ack Nak Timeout Value
RS-232 ACK NAK Features Enter/Exit Programming Mode RS-232 ACK NAK Timeout Value This item specifies the time the scanner will wait for an ACK character from the host following a label transmission. • 0 = Infinite timeout • 1 - 75 = Timeout in 200-millisecond increments To set the ACK NAK Timeout Value: 1.
Page 104: Ack Nak Retry Count
Enter/Exit Programming Mode RS-232 ACK NAK Features RS-232 ACK NAK Retry Count This feature sets the number of times for the scanner to retry a label transmis- sion under a retry condition. To set the RS-232 ACK NAK Retry Count: 1.
Page 105: Ack Nak Error Handling
RS-232 ACK NAK Features Enter/Exit Programming Mode RS-232 ACK NAK Error Handling This item specifies the method the scanner will use to handle errors detected while waiting to receive the ACK character from the host. Errors include unrec- ognized host commands and communication errors such as parity or framing errors.
Page 106: Rs-232 Indicate Transmission Failure
Enter/Exit Programming Mode RS-232 Indicate Transmission Failure RS-232 Indicate Transmission Failure This feature enables / disables the ability of the scanner to sound a bad label beep indication when a transmission failure occurs. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 107: Data Editing
Data Editing starting on page 98 DITING VERVIEW starting on page 99 LOBAL REFIX UFFIX Global Prefix on page 99 • Global Suffix on page 100 • starting on page 101 AIM ID starting on page 102 ABEL Label ID Control on page 102 •...
Page 108: Data Editing Overview
Data Editing Overview Data Editing Overview When a barcode is scanned, additional information can be sent to the host computer along with the barcode data. This combination of barcode data and supplementary user-defined data is called a “message string.” The features in this chapter can be used to build specific user-defined data into a message string.
Page 109: Global Prefix/Suffix
Global Prefix Enter/Exit Programming Mode Global Prefix/Suffix Global Prefix This feature applies to RS-232 (Standard or Wincor-Nixdorf), USB-COM, USB- TEC, and USB Keyboard interfaces. It specifies the prefix that is added to the beginning of label transmission. To specify the Global Prefix Character(s): 1.
Page 110: Global Suffix
Enter/Exit Programming Mode Global Suffix Global Suffix This feature applies to RS-232 (Standard or Wincor-Nixdorf), USB-COM, USB- TEC, and USB Keyboard interfaces. It specifies the suffix that is added to end of a label transmission. Three standard options are available below. Contact your dealer for other alternate settings for this feature.
Page 111: Aim Id
Global Suffix Enter/Exit Programming Mode AIM ID AIM (Automatic Identification Manufacturers) label identifiers are assigned from a globally standardized list — as opposed to custom label ID characters you select yourself — and can be included with scanned barcode data. AIM label identifiers consist of three characters as follows: •...
Page 112: Label Id
Enter/Exit Programming Mode Label ID Control Label ID Label ID Control This feature specifies whether or not Label IDs are transmitted to the host and if so, whether to attach them as a prefix or suffix. Choices are: • Disable •...
Page 113: Setting Label Id
Setting Label ID Enter/Exit Programming Mode Setting Label ID This feature allows the setting of custom Label ID character(s) for each available symbology type if other than the default Label ID is desired. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 114: Symbologies - Label Id
Enter/Exit Programming Mode 1D Symbologies - Label ID 1D Symbologies - Label ID 052B(CR) Default Label ID for this symbology is: 6F= o Anker Plessey Label ID 0037(CR) Default Label ID for this symbology is: 25 = % Codabar Label ID 0039(CR) Default Label ID for this symbology is: 23 = #...
Page 115 1D Symbologies - Label ID Enter/Exit Programming Mode 1D Symbologies (continued) 0552(CR) Default Label ID for this symbology is: 2459 = $Y Code39 Danish PPT Label ID 0553(CR) Default Label ID for this symbology is: 2459 = $Y Code39 LaPoste Label ID 0554(CR) Default Label ID for this symbology is:...
Page 116 Enter/Exit Programming Mode 1D Symbologies - Label ID 1D Symbologies (continued) 0366(CR) Default Label ID for this symbology is: 5234 = R4 DataBar Omnidirectional Composite Label ID 04DA(CR) Default Label ID for this symbology is: 5234 = R4 DataBar Omnidirectional Label ID 0419(CR) Default Label ID for this symbology is: 50 = P...
Page 117 1D Symbologies - Label ID Enter/Exit Programming Mode 1D Symbologies (continued) 0034(CR) Default Label ID for this symbology is: 4646 = FF EAN-8 5-Digit Supplemental Label ID 0026(CR) Default Label ID for this symbology is: 4646 = FF EAN-8 Label ID 05B4(CR) Default Label ID for this symbology is: 4646 = FF...
Page 118 Enter/Exit Programming Mode 1D Symbologies - Label ID 1D Symbologies (continued) 034C(CR) Default Label ID for this symbology is: 4941 = IA I 2 of 5 IATA Label ID 0557(CR) Default Label ID for this symbology is: 65 = e I 2 of 5 CIP HR Label ID 046A(CR) Default Label ID for this symbology is:...
Page 119 1D Symbologies - Label ID Enter/Exit Programming Mode 1D Symbologies (continued) 0024(CR) Default Label ID for this symbology is: 41 = A UPC-A Label ID 002D(CR) Default Label ID for this symbology is: 41 = A UPC-A 2-Digit Supplemental Label ID 002E(CR) Default Label ID for this symbology is: 41 = A...
Page 120: Symbologies
Enter/Exit Programming Mode 2D Symbologies 2D Symbologies 0435(CR) Default Label ID for this symbology is: 417A = Az Aztec Label ID 0105(CR) Default Label ID for this symbology is: 446D = Dm Data Matrix Label ID 0538CR) Default Label ID for this symbology is: 2464 = $d Dotcode Label ID 125D(CR)
Page 121 2D Symbologies Enter/Exit Programming Mode 2D Symbologies (continued) 05A9(CR) Default Label ID for this symbology is: 50 = P PDF 417 Label ID 03DC(CR) Default Label ID for this symbology is: 5152 = QR QR Code Label ID Product Reference Guide...
Page 122: Postal Codes
Enter/Exit Programming Mode Postal Codes Postal Codes 052C(CR) Default Label ID for this symbology is: 244C = $L Postnet Label ID 052D(CR) Default Label ID for this symbology is: 2457 = $W Planet Code Label ID 052E(CR) Default Label ID for this symbology is: 244D = $M Royal Mail Label ID 052F(CR)
Page 123: Global Mid-Label Id
Global Mid-Label ID Enter/Exit Programming Mode Global Mid-Label ID This feature specifies a global mid-label ID that is added between two barcodes for transmission. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 124: Case Conversion
Enter/Exit Programming Mode Global Mid-Label ID Case Conversion This option can change the case of all alphabetic characters in scanned barcode data to upper or lower case. Case conversion affects ONLY scanned barcode data, and does not affect Label ID, Prefix, Suffix, or other appended data. NOTE To set this feature: 1.
Page 125: Character Conversion
Global Mid-Label ID Enter/Exit Programming Mode Character Conversion Character conversion is an eight byte configuration item. The eight bytes are 4 character pairs represented in hexadecimal ASCII values. The first character in the pair is the character that will be converted. The second character in the pair is the character to convert to.
Page 126: 1D Symbology Programming
1D Symbology Programming 1D Symbologies If the scanner’s interface type must be changed, always be sure that interface con- figuration is the FIRST item scanned during a programming session. (Selecting an interface type resets ALL other configuration items — including symbology pro- gramming —...
Page 127: Coupon Control
Coupon Control Enable Enter/Exit Programming Mode Coupon Control Coupon Control Enable This feature is used to control the method of processing coupon labels. For the purposes of this feature, coupon labels are defined as: 1. UPC-A labels that start with a ‘5’ 2.
Page 128 Enter/Exit Programming Mode Coupon Control Enable Coupon Control Enable (continued) 03B902(CR) Coupon Control = Enable GS1 DataBar Expanded Coupons 03B903CR) Coupon Control = Priority to UPC-A Coupons 03B904(CR) DEFAULT Coupon Control = Priority to GS1 DataBar Expanded Coupons Magellan™ 1500i...
Page 129: Coupon Label Priority Timer
Coupon Label Priority Timer Enter/Exit Programming Mode Coupon Label Priority Timer This feature sets the duration of the UPCA / DataBar coupon label priority timer. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 130: Upc-A
Enter/Exit Programming Mode UPC-A Enable UPC-A UPC-A Enable Enables/disables the ability of the scanner to decode UPC-A labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 131: Upc-A Number System Character Transmission
UPC-A Number System Character Transmission Enter/Exit Programming Mode UPC-A Number System Character Transmission Enables/disables transmission of a UPC-A number system character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 132: Upc-A Check Character Transmission
Enter/Exit Programming Mode UPC-A Check Character Transmission UPC-A Check Character Transmission Enables/disables transmission of a UPC-A check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 133: Upc-A Minimum Read
UPC-A Minimum Read Enter/Exit Programming Mode UPC-A Minimum Read This feature specifies the minimum number of consecutive UPC-A decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 134: Expand Upc-A To Ean-13
Enter/Exit Programming Mode Expand UPC-A to EAN-13 Expand UPC-A to EAN-13 Enables/disables expansion of UPC-A labels to EAN/JAN-13. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 135: Upc-E
UPC-E Enable Enter/Exit Programming Mode UPC-E UPC-E Enable Enables/disables the ability of the scanner to decode UPC-E labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 136: Upc-E Number System Character Transmission
Enter/Exit Programming Mode UPC-E Number System Character Transmission UPC-E Number System Character Transmission Enables/disables transmission of a UPC-E number system character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 137: Upc-E Check Character Transmission
UPC-E Check Character Transmission Enter/Exit Programming Mode UPC-E Check Character Transmission Enables/disables transmission of a UPC-E check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 138: Expand Upc-E To Upc-A
Enter/Exit Programming Mode Expand UPC-E to UPC-A Expand UPC-E to UPC-A Enables/disables expansion of UPC-E labels to UPC-A. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 139: Expand Upc-E To Ean-13
Expand UPC-E to EAN-13 Enter/Exit Programming Mode Expand UPC-E to EAN-13 Enables/disables expansion of UPC-E labels to EAN/JAN-13. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 140: Upc-E Minimum Read
Enter/Exit Programming Mode UPC-E Minimum Read UPC-E Minimum Read This feature specifies the minimum number of consecutive UPC-E decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 141: 131
EAN-13 Enable Enter/Exit Programming Mode EAN-13 EAN-13 Enable Enables/disables the ability of the scanner to decode EAN/JAN-13 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 142: Ean-13 First Character Transmission
Enter/Exit Programming Mode EAN-13 First Character Transmission EAN-13 First Character Transmission Enables/disables transmission of EAN/JAN-13 first character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 143: Ean-13 Check Character Transmission
EAN-13 Check Character Transmission Enter/Exit Programming Mode EAN-13 Check Character Transmission Enables/disables transmission of an EAN/JAN-13 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 144: Ean-13 Isbn Conversion Enable
Enter/Exit Programming Mode EAN-13 ISBN Conversion Enable EAN-13 ISBN Conversion Enable Enables/disables conversion of EAN/JAN-13 labels starting with 978 to Bookland ISBN labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 145: Ean-13 Minimum Read
EAN-13 Minimum Read Enter/Exit Programming Mode EAN-13 Minimum Read This feature specifies the minimum number of consecutive EAN-13 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 146: 136
Enter/Exit Programming Mode EAN-8 Enable EAN-8 EAN-8 Enable Enables/disables the ability of the scanner to decode EAN/JAN-8 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 147: Ean-8 Check Character Transmission
EAN-8 Check Character Transmission Enter/Exit Programming Mode EAN-8 Check Character Transmission Enables/disables transmission of an EAN/JAN-8 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 148: Expand Ean-8 To Ean-13
Enter/Exit Programming Mode Expand EAN-8 to EAN-13 Expand EAN-8 to EAN-13 Enables/disables expansion of EAN/JAN-8 labels to EAN/JAN-13. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 149: Ean-8 Minimum Read
EAN-8 Minimum Read Enter/Exit Programming Mode EAN-8 Minimum Read This feature specifies the minimum number of consecutive EAN-8 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 150: Ean-8 Guard Insertion
Enter/Exit Programming Mode EAN-8 Guard Insertion EAN-8 Guard Insertion This setting enables the insertion of either a missing leading or trailing guard to a scanned barcode. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 151: Ean-8 Guard Substitution
EAN-8 Guard Substitution Enter/Exit Programming Mode EAN-8 Guard Substitution This setting enables the scanner to substitute a guard pattern for even-parity 6 for EAN8/JAN8 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 152: Ean-8/Jan-8 Both Guards Substitution
Enter/Exit Programming Mode EAN-8/Jan-8 Both Guards Substitution EAN-8/Jan-8 Both Guards Substitution Enables/disables the ability of the scanner to find an EAN/JAN8 guard pattern in cases where the EAN/JAN8 margin makes the guard look like a character. To set this feature: 1.
Page 153: Ean-8 Stitch Exact Label Halves
EAN-8 Stitch Exact Label Halves Enter/Exit Programming Mode EAN-8 Stitch Exact Label Halves This setting enables the stitching of exact EAN-8 label halves with no overlap- ping characters. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 154: Ean-8 Stitch Unlike Label Halves
Enter/Exit Programming Mode EAN-8 Stitch Unlike Label Halves EAN-8 Stitch Unlike Label Halves This setting enables the stitching of two EAN-8 label halves together that may have different characters. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 155: Ean-8 Minimum Segment Length
EAN-8 Minimum Segment Length Enter/Exit Programming Mode EAN-8 Minimum Segment Length Specifies the minimum number of characters necessary in an EAN-8/JAN-8 label segment in order for the scanner to accept a label for decoding. Selectable from 5 to 15 characters. Default setting for this feature is: 08 (8 characters). 049D05(CR) EAN-8 Minimum Segment Length = 5 characters...
Page 156 Enter/Exit Programming Mode EAN-8 Minimum Segment Length EAN-8 Minimum Segment Length (continued) 049D0C(CR) EAN-8 Minimum Segment Length = 12 characters 049D0D(CR) EAN-8 Minimum Segment Length = 13 characters 049D0E(CR) EAN-8 Minimum Segment Length = 14 characters 049D0F(CR) EAN-8 Minimum Segment Length = 15 characters Magellan™...
Page 157: Ean-8 Decoding Levels
EAN-8 Decoding Levels Enter/Exit Programming Mode EAN-8 Decoding Levels Decoding levels allow the decoder to be set to perform at one of four selectable levels: • Very Conservative — Slower scan time, virtually eliminates misreads. The most secure setting. • Slightly More Aggressive —...
Page 158: Other Upc/Ean Options
Enter/Exit Programming Mode EAN-8 Decoding Levels Other UPC/EAN Options The following pages contain other selectable features for UPC/EAN symbolo- gies: • In-Store Printed Label Minimum Read on page 149 • UPC/EAN Correlation on page 150 • UPC/EAN Guard Insertion on page 151 •...
Page 159: In-Store Printed Label Minimum Read
In-Store Printed Label Minimum Read Enter/Exit Programming Mode In-Store Printed Label Minimum Read This feature specifies the minimum number of consecutive In-Store Printed Label decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 160: Upc/Ean Correlation
Enter/Exit Programming Mode UPC/EAN Correlation UPC/EAN Correlation Enables/disables character correlation for UPC/EAN. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 161: Upc/Ean Guard Insertion
UPC/EAN Guard Insertion Enter/Exit Programming Mode UPC/EAN Guard Insertion This setting enables the insertion of either a missing leading or trailing guard to a scanned barcode. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 162: Upc/Ean Stitch Exact Label Halves
Enter/Exit Programming Mode UPC/EAN Stitch Exact Label Halves UPC/EAN Stitch Exact Label Halves This setting enables the stitching of exact UPC-A/EAN-13 label halves with no overlapping characters. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 163: Upc/Ean Stitch Unlike Label Halves
UPC/EAN Stitch Unlike Label Halves Enter/Exit Programming Mode UPC/EAN Stitch Unlike Label Halves This setting enables the stitching of two UPC-A/EAN-13 label halves together that may have different characters. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 164: Upc/Ean Minimum Segment Length
Enter/Exit Programming Mode UPC/EAN Minimum Segment Length UPC/EAN Minimum Segment Length This feature specifies the minimum number of characters needed in a UPC/EAN segment in order to be accepted for decoding. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 165 UPC/EAN Minimum Segment Length Enter/Exit Programming Mode UPC/EAN Minimum Segment Length (continued) 048F0A(CR) UPC/EAN Minimum Segment Length = 10 Characters 048F0B(CR) UPC/EAN Minimum Segment Length = 11 Characters 048F0C(CR) UPC/EAN Minimum Segment Length = 12 Characters 048F0D(CR) UPC/EAN Minimum Segment Length = 13 Characters 048F0E(CR) UPC/EAN Minimum Segment Length = 14 Characters 048F0F(CR)
Page 166: Price Weight Check
Enter/Exit Programming Mode Price Weight Check Price Weight Check Enables/disables calculation and verification of price/weight check digits. Applies to all UPC-A and EAN/JAN-13 labels with eligible Number System/First Character digits. Options are: • Disable • 4-digit price/weight • 5-digit price/weight •...
Page 167 Price Weight Check Enter/Exit Programming Mode Price Weight Check (continued) 005C03(CR) Price Weight Check = 4-digit European price/weight 005C04(CR) Price Weight Check = 5-digit European price/weight Product Reference Guide...
Page 168: Enable Ean Two Label
Enter/Exit Programming Mode Enable EAN Two Label Enable EAN Two Label Enables/disables the ability of the scanner to decode EAN two-label pairs. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 169: Ean Two Label Minimum Read
EAN Two Label Minimum Read Enter/Exit Programming Mode EAN Two Label Minimum Read This feature specifies the minimum number of consecutive EAN Two Label decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 170: Ean Two Label Combined Transmission
Enter/Exit Programming Mode EAN Two Label Combined Transmission EAN Two Label Combined Transmission Enables/disables the transmitting of an EAN two label pair as one label. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 171: Add-Ons
Add-ons Enter/Exit Programming Mode Add-ons The scanner is capable of processing different types of add-on codes, includ- ing: • 2-Digit Supplemental • 5-Digit Supplemental Options are provided on the following pages for your convenience: • Disable all add-ons — The scanner will not look for or read add-ons. •...
Page 172: P2 Add-On Minimum Read
Enter/Exit Programming Mode Add-ons P2 Add-on Minimum Read This feature specifies the minimum number of times a P2 add-on must decode before it is marked valid. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 173 Add-ons Enter/Exit Programming Mode P2 Add-on Minimum Read (continued) 005F07(CR) P2 Add-on Minimum Read = 7 005F08(CR) P2 Add-on Minimum Read = 8 005F09(CR) P2 Add-on Minimum Read = 9 005F0A(CR) P2 Add-on Minimum Read = 10 005F0B(CR) P2 Add-on Minimum Read = 11 005F0C(CR) P2 Add-on Minimum Read = 12 005F0D(CR)
Page 174 Enter/Exit Programming Mode Add-ons P2 Add-on Minimum Read (continued) 005F0E(CR) P2 Add-on Minimum Read = 14 005F0F(CR) P2 Add-on Minimum Read = 15 Magellan™ 1500i...
Page 175: P5 Add-On Minimum Read
Add-ons Enter/Exit Programming Mode P5 Add-on Minimum Read This feature specifies the minimum number of times a P5 add-on must decode before it is marked valid. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 176 Enter/Exit Programming Mode Add-ons P5 Add-on Minimum Read (continued) 007D07(CR) P5 Add-on Minimum Read = 7 007D08(CR) P5 Add-on Minimum Read = 8 007D09(CR) P5 Add-on Minimum Read = 9 007D0A(CR) P5 Add-on Minimum Read = 10 007D0B(CR) P5 Add-on Minimum Read = 11 007D0C(CR) P5 Add-on Minimum Read = 12 007D0D(CR)
Page 177 Add-ons Enter/Exit Programming Mode P5 Add-on Minimum Read (continued) 007D0E(CR) P5 Add-on Minimum Read = 14 007D0F(CR) P5 Add-on Minimum Read = 15 Product Reference Guide...
Page 178: Upc/Ean Composites
Enter/Exit Programming Mode UPC/EAN Composites UPC/EAN Composites Enables/Disables Composites for the UPC/EAN families of labels. The value is a bit field where the bits mean the following: • A setting of 0 (zero) disables this feature. • Bit0 - if set enabled Composites for UPCE, If clear disables Composites for UPCE •...
Page 179: Gtin
GTIN Enable Enter/Exit Programming Mode GTIN GTIN Enable Enables/Disables the ability to convert UPCE, UPCA, EAN8, and EAN13 labels into the GTIN 14-character format. If add-on information is present on the base label prior to the conversion taking place, the add-on information will be appended to the converted GTIN barcode.
Page 180: Gs1 Databar
Enter/Exit Programming Mode DataBar Omnidirectional Enable GS1 DataBar The symbology family GS1 DataBar™ was formerly known as Reduced Space Symbology (RSS). For the purpose of simplicity, GS1 DataBar variants are listed in this manual as “DataBar.” DataBar Omnidirectional DataBar Omnidirectional Enable Enables/disables the ability of the scanner to decode DataBar Omnidirectional labels.
Page 181: Databar Omnidirectional/Ean-128 Emulation
DataBar Omnidirectional/EAN-128 Emulation Enter/Exit Programming Mode DataBar Omnidirectional/EAN-128 Emulation Enables/disables the ability of DataBar Omnidirectional to be transmitted as EAN-128. 1. To set this feature: 2. Scan the Enter/Exit Programming Mode barcode at the top of the page. 3. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 182: Databar Omnidirectional 2D Component Enable
Enter/Exit Programming Mode DataBar Omnidirectional 2D Component Enable DataBar Omnidirectional 2D Component Enable When this feature is enabled, the software will not decode an DataBar Omnidi- rectional barcode with a 2D component associated with it, and the 2D compo- nent will be discarded. To set this feature: 1.
Page 183: Databar Omnidirectional Minimum Read
DataBar Omnidirectional Minimum Read Enter/Exit Programming Mode DataBar Omnidirectional Minimum Read This feature specifies the minimum number of consecutive DataBar Omnidirec- tional decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 184: Databar Omnidirectional Double Read Timeout
Enter/Exit Programming Mode DataBar Omnidirectional Double Read Timeout DataBar Omnidirectional Double Read Timeout Specifies the minimum allowable time which must pass before reading the same DataBar Omnidirectional label again (e.g. two identical items in succession). To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 185: Databar Limited
DataBar Limited Enable Enter/Exit Programming Mode DataBar Limited DataBar Limited Enable Enables/disables the ability of the scanner to decode DataBar Limited labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 186: Databar Limited Minimum Read
Enter/Exit Programming Mode DataBar Limited Minimum Read DataBar Limited Minimum Read This feature specifies the minimum number of consecutive Databar Limited decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 187: Databar Limited 2D Component Enable
DataBar Limited 2D Component Enable Enter/Exit Programming Mode DataBar Limited 2D Component Enable This feature controls if a 2D label component be decoded when a Databar Lim- ited base label is decoded. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 188: Databar Limited Ean128 Emulation Enable
Enter/Exit Programming Mode DataBar Limited EAN128 Emulation Enable DataBar Limited EAN128 Emulation Enable Enables/disables GS1-EAN128 emulation for GS1 Databar Limited. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 189: Databar Expanded
DataBar Expanded Enable Enter/Exit Programming Mode DataBar Expanded DataBar Expanded Enable Enables/disables the ability of the scanner to decode DataBar Expanded labels. This value-added feature is a factory-programmed option. Con- tact your dealer for information about upgrading your system to include this advanced capability.
Page 190: Databar Expanded Ean-128 Emulation
Enter/Exit Programming Mode DataBar Expanded EAN-128 Emulation DataBar Expanded EAN-128 Emulation Enables/disables EAN 128 emulation for DataBar Expanded. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 191: Databar Expanded 2D Component Enable
DataBar Expanded 2D Component Enable Enter/Exit Programming Mode DataBar Expanded 2D Component Enable When this feature is enabled, the software will not decode an DataBar Expanded barcode with a 2D component associated with it, and the 2D component will be discarded.
Page 192: Databar Expanded Minimum Read
Enter/Exit Programming Mode DataBar Expanded Minimum Read DataBar Expanded Minimum Read This feature specifies the minimum number of consecutive DataBar Expanded decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 193: Databar Expanded Length Control
DataBar Expanded Length Control Enter/Exit Programming Mode DataBar Expanded Length Control This feature specifies either variable-length or fixed-length decoding for DataBar Expanded. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 194: Databar Expanded Length 1
Enter/Exit Programming Mode DataBar Expanded Length 1 DataBar Expanded Length 1 Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode. Length includes the barcode's data charac- ters only. To set this feature: 1.
Page 195: Databar Expanded Length 2
DataBar Expanded Length 2 Enter/Exit Programming Mode DataBar Expanded Length 2 Length 2 is the maximum label length if in variable length mode, or the second fixed length if in fixed length mode. Length includes the barcode's data char- acters only. When in Fixed Length mode, if Length 2 is set to the value of 00 (zero), then only Length 1 will apply.
Page 196: Databar Expanded Reverse Retry
Enter/Exit Programming Mode DataBar Expanded Reverse Retry DataBar Expanded Reverse Retry Enables/disables the reading of out of specification labels where the last row has been printed in reverse. • When enabled, DataBar Expanded Stacked labels that have the last row incorrectly printed in reverse will be re-decoded.
Page 197: Code 39
Code 39 Enable Enter/Exit Programming Mode Code 39 Code 39 Enable Enables/disables the ability of the scanner to decode Code 39 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 198: Code 39 Start Stop Character Transmission
Enter/Exit Programming Mode Code 39 Start Stop Character Transmission Code 39 Start Stop Character Transmission Enables/disables transmission of Code 39 start and stop characters. This item is ignored when the advanced feature, Full Label Edit, is enabled NOTE To set this feature: 1.
Page 199: Code 39 Check Character Calculation
Code 39 Check Character Calculation Enter/Exit Programming Mode Code 39 Check Character Calculation Enables/disables calculation and verification of an optional Code 39 check character. When disabled, any check character in label is treated as a data char- acter. If check calculation is disabled, the risk is increased that a mis- read can occur.
Page 200: Code 39 Check Character Transmission
Enter/Exit Programming Mode Code 39 Check Character Transmission Code 39 Check Character Transmission Enables/disables transmission of optional Code 39 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 201: Code 39 Full Ascii
Code 39 Full ASCII Enter/Exit Programming Mode Code 39 Full ASCII Enables/disables the ability of the scanner to translate to Code 39 full ASCII labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 202: Code 39 Minimum Read
Enter/Exit Programming Mode Code 39 Minimum Read Code 39 Minimum Read This feature specifies the minimum number of consecutive Code 39 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 203: Code 39 Length Control
Code 39 Length Control Enter/Exit Programming Mode Code 39 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 39. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 204: Code 39 Length 1
Enter/Exit Programming Mode Code 39 Length 1 Code 39 Length 1 If Code 39 Length Control is set to Fixed-Length decoding, this feature speci- fies Code 39 first fixed length. If Code 39 Length Control is set to Variable- Length decoding, this feature specifies the minimum label length. To set this feature: 1.
Page 205: Code 39 Length 2
Code 39 Length 2 Enter/Exit Programming Mode Code 39 Length 2 If Code 39 Length Control is set to Fixed-Length decoding, this feature speci- fies Code 39 second fixed length. If Code 39 Length Control is set to Variable- Length decoding, this feature specifies the maximum label length. When in Fixed Length mode, if Length 2 is set to the value of 00, then only Length 1 will apply NOTE...
Page 206: Code 39 Stitching
Enter/Exit Programming Mode Code 39 Stitching Code 39 Stitching Enables/disables stitching for Code 39 labels. When parts of a Code 39 barcode are presented to the scanner with this feature enabled, the barcode parts will be assembled by the scanner’s software, and the data will be decoded if all bar- code proofing requirements are met.
Page 207: Code 39 Require Margins
Code 39 Require Margins Enter/Exit Programming Mode Code 39 Require Margins Enables/disables the requirement that quiet zones be present in a Code 39 barcode. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 208: Code 32 Italian Pharmacode
Enter/Exit Programming Mode Code 32 Italian Pharmacode Enable Code 32 Italian Pharmacode Code 32 Italian Pharmacode Enable Enables/disables the ability of the scanner to decode Italian Pharmaceutical Code 39 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 209: Code 32 Start Stop Character Transmission
Code 32 Start Stop Character Transmission Enter/Exit Programming Mode Code 32 Start Stop Character Transmission Enables/ disables transmission of start and stop characters for Code 32. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1.
Page 210: Code 32 Check Character Transmission
Enter/Exit Programming Mode Code 32 Check Character Transmission Code 32 Check Character Transmission Enables/disables transmission of Code 32 check character. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 211: Code 128
Code 128 Enable Enter/Exit Programming Mode Code 128 Code 128 Enable Enables/disables the ability of the scanner to decode Code 128 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 212: Code 128 Transmit Function Characters
Enter/Exit Programming Mode Code 128 Transmit Function Characters Code 128 Transmit Function Characters Enables/disables transmission of Code 128 function characters 1, 2, 3, and 4. Disabled is the recommended setting for all interfaces. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 213: Expand Code128 To Code 39
Expand Code128 to Code 39 Enter/Exit Programming Mode Expand Code128 to Code 39 Enables/disables expansion of Code 128 labels to Code 39. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 214: Code 128 Minimum Read
Enter/Exit Programming Mode Code 128 Minimum Read Code 128 Minimum Read This feature specifies the minimum number of consecutive Code 128 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 215: Code 128 Length Control
Code 128 Length Control Enter/Exit Programming Mode Code 128 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 128. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 216: Code 128 Length 1
Enter/Exit Programming Mode Code 128 Length 1 Code 128 Length 1 If Code 128 Length Control is set to Fixed-Length decoding, this feature speci- fies Code 128 first fixed length. If Code 128 Length Control is set to Variable- Length decoding, this feature specifies the minmum label length. To set this feature: 1.
Page 217: Code 128 Length 2
Code 128 Length 2 Enter/Exit Programming Mode Code 128 Length 2 If Code 128 Length Control is set to Fixed-Length decoding, this feature speci- fies Code 128 second fixed length. If Code 128 Length Control is set to Vari- able-Length decoding, this feature specifies the maximum label length. When in Fixed Length mode, if Length 2 is set to the value of 00 (zero), then only Length 1 will apply.
Page 218: Code 128 Stitching
Enter/Exit Programming Mode Code 128 Stitching Code 128 Stitching Enables/disables stitching for Code 128 labels. When parts of a Code 128 bar- code are presented to the scanner with this feature enabled, the barcode parts will be assembled by the scanner’s software, and the data will be decoded if all barcode proofing requirements are met.
Page 219: 209
EAN-128 Enable Enter/Exit Programming Mode EAN-128 EAN-128 Enable Enables/disables the ability of the scanner to translate EAN128 labels to the EAN128 data format. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 220: Interleaved 2 Of 5 (I 2 Of 5)
Enter/Exit Programming Mode Interleaved 2 of 5 (I 2 OF 5) Enable Interleaved 2 of 5 (I 2 OF 5) Interleaved 2 of 5 (I 2 OF 5) Enable Enables/disables the ability of the scanner to decode Interleaved 2 of 5 labels. To set this feature: 1.
Page 221: I 2 Of 5 Check Character Calculation
I 2 of 5 Check Character Calculation Enter/Exit Programming Mode I 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Interleaved 2 of 5 check character. If check character calculation is disabled, the risk is increased that a misread can occur.
Page 222: I 2 Of 5 Check Character Transmission
Enter/Exit Programming Mode I 2 of 5 Check Character Transmission I 2 of 5 Check Character Transmission Enables/disables transmission of an optional Interleaved 2 of 5 check charac- ter. This feature applies only when I 2 of 5 Check Character Calculation is enabled.
Page 223: I 2 Of 5 Minimum Read
I 2 of 5 Minimum Read Enter/Exit Programming Mode I 2 of 5 Minimum Read This feature specifies the minimum number of consecutive I 2 of 5 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 224: I 2 Of 5 Length Control
Enter/Exit Programming Mode I 2 of 5 Length Control I 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for I 2 of 5. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 225: I 2 Of 5 Length 1
I 2 of 5 Length 1 Enter/Exit Programming Mode I 2 of 5 Length 1 If I 2 of 5 Length Control is set to Fixed-Length decoding, this feature specifies I 2 of 5 first fixed length. If I 2 of 5 Length Control is set to Variable-Length decoding, this feature specifies the minimum label length.
Page 226: I 2 Of 5 Length 2
Enter/Exit Programming Mode I 2 of 5 Length 2 I 2 of 5 Length 2 If I 2 of 5 Length Control is set to Fixed-Length decoding, this feature specifies I 2 of 5 second fixed length. If I 2 of 5 Length Control is set to Variable-Length decoding, this feature specifies the maximum label length.
Page 227: Codabar
Codabar Enable Enter/Exit Programming Mode Codabar Codabar Enable Enables/disables the ability of the scanner to decode Codabar labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 228: Codabar Start Stop Character Transmission
Enter/Exit Programming Mode Codabar Start Stop Character Transmission Codabar Start Stop Character Transmission Enables/disables transmission of Codabar start and stop characters. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 229: Codabar Start Stop Character Set
Codabar Start Stop Character Set Enter/Exit Programming Mode Codabar Start Stop Character Set This feature specifies the format of transmitted Codabar start/stop characters. Options are: • ABCD/TN* E • ABCD/ABCD • abcd/tn* e • abcd/abcd To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 230: Codabar Start Stop Character Match
Enter/Exit Programming Mode Codabar Start Stop Character Match Codabar Start Stop Character Match Enables/disables the requirement that Codabar start and stop characters match. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 231: Codabar Check Character Calculation
Codabar Check Character Calculation Enter/Exit Programming Mode Codabar Check Character Calculation Enables/disables calculation and verification of an optional Codabar check character. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a barcode are treated as data characters.
Page 232: Codabar Check Character Transmission
Enter/Exit Programming Mode Codabar Check Character Transmission Codabar Check Character Transmission Enables/disables transmission of an optional Codabar check character. Applies only when Codabar Check Character Calculation is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1.
Page 233: Codabar Minimum Read
Codabar Minimum Read Enter/Exit Programming Mode Codabar Minimum Read This feature specifies the minimum number of consecutive Codabar decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 234: Codabar Length Control
Enter/Exit Programming Mode Codabar Length Control Codabar Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Codabar. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 235: Codabar Length 1
Codabar Length 1 Enter/Exit Programming Mode Codabar Length 1 If Codabar Length Control is set to Fixed-Length decoding, this feature speci- fies Codabar first fixed length. If Codabar Length Control is set to Variable- Length decoding, this feature specifies the minimum label length. To set this feature: 1.
Page 236: Codabar Length 2
Enter/Exit Programming Mode Codabar Length 2 Codabar Length 2 If Codabar Length Control is set to Fixed-Length decoding, this feature speci- fies Codabar second fixed length. If Codabar Length Control is set to Variable- Length decoding, this feature specifies the maximum label length. When in Fixed Length mode, if Length 2 is set to the value of 00 (zero), then only Length 1 will apply.
Page 237: Codabar Require Margins
Codabar Require Margins Enter/Exit Programming Mode Codabar Require Margins Enables/disables the requirement that quiet zones be present in a Codabar barcode. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 238: Code 93
Enter/Exit Programming Mode Code 93 Enable Code 93 Code 93 Enable Enables/disables the ability of the scanner to decode Code 93 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 239: Code 93 Minimum Read
Code 93 Minimum Read Enter/Exit Programming Mode Code 93 Minimum Read This feature specifies the minimum number of consecutive Code 93 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 240: Code 93 Length Control
Enter/Exit Programming Mode Code 93 Length Control Code 93 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Code 93. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 241: Code 93 Length 1
Code 93 Length 1 Enter/Exit Programming Mode Code 93 Length 1 If Code 93 Length Control is set to Fixed-Length decoding, this feature speci- fies Code 93 first fixed length. If Code 93 Length Control is set to Variable- Length decoding, this feature specifies the minimum label length. To set this feature: 1.
Page 242: Code 93 Length 2
Enter/Exit Programming Mode Code 93 Length 2 Code 93 Length 2 If Code 93 Length Control is set to Fixed-Length decoding, this feature speci- fies Code 93 second fixed length. If Code 93 Length Control is set to Variable- Length decoding, this feature specifies the maximum label length. When in Fixed Length mode, if Fixed Length 2 is set to the value of 00 (zero), then only Length 1 will apply.
Page 243: Msi
MSI Enable Enter/Exit Programming Mode MSI Enable Enables/disables the ability of the scanner to decode MSI labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 244: Msi Check Character Calculation
Enter/Exit Programming Mode MSI Check Character Calculation MSI Check Character Calculation Enables/disables calculation and verification of optional MSI check characters. If check character calculation is disabled, the risk is increased that a misread can occur. When disabled, any check characters in a barcode are treated as data characters.
Page 245: Msi Number Of Check Characters
MSI Number of Check Characters Enter/Exit Programming Mode MSI Number of Check Characters Specifies number of MSI check characters to be calculated and verified. Check characters are always modulus 10. NOTE To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 246: Msi Check Character Transmission
Enter/Exit Programming Mode MSI Check Character Transmission MSI Check Character Transmission Enables/disables transmission of optional MSI check characters. This feature applies only when MSI Check Character Calcu- lation on page 234 is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled. NOTE To set this feature: 1.
Page 247: Msi Minimum Read
MSI Minimum Read Enter/Exit Programming Mode MSI Minimum Read This feature specifies the minimum number of consecutive MSI decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 248: Msi Length Control
Enter/Exit Programming Mode MSI Length Control MSI Length Control This feature specifies whether variable-length or fixed-length decoding will be set for MSI. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan your selection from the barcodes below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 249: Msi Length 1
MSI Length 1 Enter/Exit Programming Mode MSI Length 1 If MSI Length Control is set to Fixed-Length decoding, this feature specifies MSI first fixed length. If MSI Length Control is set to Variable-Length decoding, this feature specifies the minimum label length. To set this feature: 1.
Page 250: Msi Length 2
Enter/Exit Programming Mode MSI Length 2 MSI Length 2 If MSI Length Control is set to Fixed-Length decoding, this feature specifies MSI second fixed length. If MSI Length Control is set to Variable-Length decoding, this feature specifies the maximum label length. When in Fixed Length mode, if Length 2 is set to the value 00 (zero), then only Length 1 will apply.
Page 251: Standard 2 Of 5
Standard 2 of 5 Enable Enter/Exit Programming Mode Standard 2 of 5 Standard 2 of 5 Enable Enables/disables the ability of the scanner to decode Standard 2 of 5 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 252: Standard 2 Of 5 Check Character Calculation
Enter/Exit Programming Mode Standard 2 of 5 Check Character Calculation Standard 2 of 5 Check Character Calculation Enables/disables calculation and verification of an optional Standard 2 of 5 check character. If check character calculation is disabled, the risk is increased that a misread can occur.
Page 253: Standard 2 Of 5 Check Character Transmission
Standard 2 of 5 Check Character Transmission Enter/Exit Programming Mode Standard 2 of 5 Check Character Transmission Enables/disables transmission of an optional Standard 2 of 5 check character. This feature applies only when Standard 2 of 5 Check Char- acter Calculation on page 242 is enabled. This item is ignored when the advanced feature, Full Label Edit, is enabled.
Page 254: Standard 2 Of 5 Minimum Read
Enter/Exit Programming Mode Standard 2 of 5 Minimum Read Standard 2 of 5 Minimum Read This feature specifies the minimum number of consecutive Standard 2 of 5 decodes before is accepted as good read. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 255: Standard 2 Of 5 Correlation
Standard 2 of 5 Correlation Enter/Exit Programming Mode Standard 2 of 5 Correlation Enables/disables character correlation for Standard 2 of 5. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 256: Standard 2 Of 5 Length Control
Enter/Exit Programming Mode Standard 2 of 5 Length Control Standard 2 of 5 Length Control This feature specifies whether variable-length or fixed-length decoding will be set for Standard 2 of 5. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 257: Standard 2 Of 5 Length 1
Standard 2 of 5 Length 1 Enter/Exit Programming Mode Standard 2 of 5 Length 1 If Standard 2 of 5 Length Control is set to Fixed-Length decoding, this feature specifies Standard 2 of 5 first fixed length. If Standard 2of 5 Length Control is set to Variable-Length decoding, this feature specifies the minimum label length.
Page 258: Standard 2 Of 5 Length 2
Enter/Exit Programming Mode Standard 2 of 5 Length 2 Standard 2 of 5 Length 2 If Standard 2 of 5 Length Control is set to Fixed-Length decoding, this feature specifies Standard 2 of 5 second fixed length. If Standard 2of 5 Length Control is set to Variable-Length decoding, this feature specifies the maximum label length.
Page 259: Symbologies/Postal Codes
2D Symbologies/Postal Codes If the scanner’s interface type must be changed, always be sure that interface configuration is the FIRST item scanned during a program- ming session. (Selecting an interface type resets ALL other configura- tion items — including symbology programming — to the factory NOTE default for that interface type.) The following pages contain configuration information concerning the various...
Page 260: Data Matrix
Enter/Exit Programming Mode Data Matrix Enable Data Matrix Data Matrix Enable Enables/disables the ability of the scanner to decode Data Matrix labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 261: Data Matrix Length Control
Data Matrix Length Control Enter/Exit Programming Mode Data Matrix Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding —...
Page 262: Data Matrix Length 1, Length 2 Programming Instructions
Enter/Exit Programming Mode Data Matrix Length Control Data Matrix Length 1, Length 2 Programming Instructions If Data Matrix Length Control is set to Fixed-Length decoding, this feature specifies Data Matrix first fixed length. If Data Matrix Length Control is set to Variable-Length decoding, this feature specifies the minimum label length.
Page 263: Gs1 Datamatrix Enable
GS1 Datamatrix Enable Enter/Exit Programming Mode GS1 Datamatrix Enable Enables/disables the ability of the scanner to decode GS1 Datamatrix labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 264: Pdf 417
Enter/Exit Programming Mode PDF 417 Enable PDF 417 PDF 417 Enable Enables the processing of PDF417 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 265: Pdf 417 Length Control
PDF 417 Length Control Enter/Exit Programming Mode PDF 417 Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding —...
Page 266: Pdf 417 Length 1, Length 2 Programming Instructions
Enter/Exit Programming Mode PDF 417 Length Control PDF 417 Length 1, Length 2 Programming Instructions If PDF417 Length Control is set to Fixed-Length decoding, this feature specifies PDF417 first fixed length. If PDF417 Length Control is set to Variable-Length decoding, this feature specifies the minimum label length. This tag is only valid for units with a model ID that supports PDF.
Page 267: Pdf 417 Read Option
PDF 417 Read Option Enter/Exit Programming Mode PDF 417 Read Option This feature specifies an additional read control option for PDF 417 barcodes. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 268: Micro Pdf 417
Enter/Exit Programming Mode Micro PDF 417 Enable Micro PDF 417 Micro PDF 417 Enable Enables/disables the ability of the scanner to decode Micro PDF 417 labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 269: Micro Pdf 417 Length Control
Micro PDF 417 Length Control Enter/Exit Programming Mode Micro PDF 417 Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding —...
Page 270: Micro Pdf 417 Length 1, Length 2 Programming Instructions
Enter/Exit Programming Mode Micro PDF 417 Length Control Micro PDF 417 Length 1, Length 2 Programming Instructions If Micro PDF 417 Length Control is set to Fixed-Length decoding, this feature specifies Micro PDF 417 first fixed length. If Micro PDF 417 Length Control is set to Variable-Length decoding, this feature specifies the minimum label length.
Page 271: Micro Pdf 417 128 Emulation
Micro PDF 417 128 Emulation Enter/Exit Programming Mode Micro PDF 417 128 Emulation This feature specifies which AIM ID to use for Micro PDF 417 labels when per- forming Code 128 or EAN 128 emulation. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 272: Qr Code
Enter/Exit Programming Mode QR Code Enable QR Code QR Code Enable Enables/disables the ability of the scanner to decode QR Code labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 273: Qr Code Length Control
QR Code Length Control Enter/Exit Programming Mode QR Code Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding —...
Page 274: Qr Code Length 1, Length 2 Programming Instructions
Enter/Exit Programming Mode QR Code Length Control QR Code Length 1, Length 2 Programming Instructions If QR Code Length Control is set to Fixed-Length decoding, this feature speci- fies QR Code first fixed length. If QR Code Length Control is set to Variable- Length decoding, this feature specifies the minimum label length.
Page 275: Qr Code Url Link Enable
QR Code URL Link Enable Enter/Exit Programming Mode QR Code URL Link Enable Enables/Disables the decoding of QR codes with a URL link on imagers. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 276: Gs1 Qr Code Enable
Enter/Exit Programming Mode QR Code URL Link Enable GS1 QR Code Enable This feature controls the ability of the scanner to decode GS1 QR Code labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 277: Micro Qr Code
Micro QR Code Enable Enter/Exit Programming Mode Micro QR Code Micro QR Code Enable Enables/disables the ability of the scanner to decode Micro QRCode labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 278: Micro Qr Code Length Control
Enter/Exit Programming Mode Micro QR Code Length Control Micro QR Code Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding —...
Page 279: Micro Qr Code Length 1, Length 2 Programming Instructions
Micro QR Code Length Control Enter/Exit Programming Mode Micro QR Code Length 1, Length 2 Programming Instructions If Micro QR Code Length Control is set to Fixed-Length decoding, this feature specifies Micro QR Code first fixed length. If Micro QR Code Length Control is set to Variable-Length decoding, this feature specifies the minimum label length.
Page 280: Aztec Code
Enter/Exit Programming Mode Aztec Enable Aztec Code Aztec Enable Enables/disables the ability of the scanner to decode Aztec labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 281: Aztec Length Control
Aztec Length Control Enter/Exit Programming Mode Aztec Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding —...
Page 282: Aztec Length 1, Length 2 Programming Instructions
Enter/Exit Programming Mode Aztec Length Control Aztec Length 1, Length 2 Programming Instructions If Aztec Length Control is set to Fixed-Length decoding, this feature specifies Aztec first fixed length. If Aztec Length Control is set to Variable-Length decoding, this feature specifies the minimum label length. Length 1 is the minimum label length if in variable length mode, or the first fixed length if in fixed length mode.
Page 283: Han Xin Code
Han Xin Enable Enter/Exit Programming Mode Han Xin Code Han Xin Enable Enables/disables the ability of the scanner to decode Han Xin labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 284: Postnet
Enter/Exit Programming Mode Postnet Enable POSTAL CODE SELECTION Enables/disables the ability of the scanner to decode labels of the specified postal symbology. Postnet Postnet Enable Enables/disables the ability of the scanner to decode Postnet labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2.
Page 285: Planet Code
Planet Code Enable Enter/Exit Programming Mode Planet Code Planet Code Enable Enables/disables the ability of the scanner to decode Planet Code labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 286: Royal Mail
Enter/Exit Programming Mode Royal Mail Enable Royal Mail Royal Mail Enable Enables/disables the ability of the scanner to decode Royal Mail labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 287: Kix
Kix Enable Enter/Exit Programming Mode Kix Enable Enables/disables the ability of the scanner to decode Kix labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 288: Australia Post
Enter/Exit Programming Mode Australian Post Enable Australia Post Australian Post Enable Enables/disables the ability of the scanner to decode Australia Post labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 289: Japan Post
Japan Post Enable Enter/Exit Programming Mode Japan Post Japan Post Enable Enables/disables the ability of the scanner to decode Japan Post labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 290: Imb
Enter/Exit Programming Mode IMB Enable IMB Enable Enables/disables the ability of the scanner to decode IMB labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 291: Sweden Post
Sweden Post Enable Enter/Exit Programming Mode Sweden Post Sweden Post Enable Enables/disables the ability of the scanner to decode Sweden Post labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 292: Portugal Post
Enter/Exit Programming Mode Portugal Post Enable Portugal Post Portugal Post Enable Enables/disables the ability of the scanner to decode Portugal Post labels. To set this feature: 1. Scan the Enter/Exit Programming Mode barcode at the top of the page. 2. Scan either the enable or disable barcode below. You’ll need to cover any unused barcodes on this and the facing page to ensure that the scanner reads only the barcode you intend to scan.
Page 293: Chapter 3. References
Chapter 3 References This section contains explanations and examples of selected barcode features. See the programming sections for the actual barcode labels used to configure the reader. Global Prefix/Suffix Up to 20 ASCII characters may be added as a prefix (in a position before the barcode data) and/or as a suffix (in a position following the barcode data) as indicated in Figure...
Page 294: Label Id
Label ID 5. Scan the END barcode once to finish the string, then scan END again to exit Programming Mode. If all 20 characters will be used in the prefix or suffix, do not scan the END barcode to finish the string. It is done automatically. NOTE 6.
Page 295: Label Id
Label ID Default Symbology Default ASCII Character ANKER PLESSEY 6F0000 AZTEC 417A00 Han Xin 245300 CODABAR 250000 CODE11 434500 CODE128 230000 CODE32 410000 CODE39 2A0000 CODE39 CIP 590000 CODE39 DANISH PPT 245900 CODE39 LAPOSTE 245900 CODE39 PZN 245A00 CODE93 & 260000 DATABAR 14 523400...
Page 296 Label ID Default Symbology Default ASCII Character EAN8 COMPOSITE 464600 FOLLET 2OF5 4F0000 GTIN 470000 GTIN2 473200 GTIN5 473500 I2OF5 690000 I2OF5 CIP HR 650000 IATA INDUSTRIAL 2OF5 494100 ISBN 490000 ISBT128 CONCAT 660000 ISSN 6E0000 MICRO QR 245100 MICRO PDF 6D5000 400000 PDF417...
Page 297 Default Symbology Default ASCII Character UPCA P2 410000 UPCA P5 410000 UPCA COMPOSITE 410000 UPCE 450000 UPCE P2 450000 UPCE P5 450000 UPCE COMPOSITE 450000 Product Reference Guide...
Page 298: Length Control
Label ID Length Control When fixed length decoding is enabled, the scanner Fixed Length Decoding — will decode a barcode if the label length matches one of the configurable fixed lengths. When variable length decoding is enabled, the scan- Variable Length Decoding — ner will decode a barcode if the label length falls in the range of the configu- rable minimum and maximum length.
Page 299: Appendix A. Product Specifications
Appendix A Product Specifications Decoding Capability Parameter Specification Autodiscriminates All Standard 1D Codes Including GS1 Databar™ 1D / Linear Codes Linear Codes. 2D Codes Aztec Code; Data Matrix; QR Code GS1 Databar Composites; GS1 Databar Expanded Stacked; GS1 Stacked Codes Databar Stacked;...
Page 300: Environmental
Environmental Environmental Parameter Specification Ambient Light 0 - 86,100 Lux Withstands repeated drops from 1.2 m / 4.0 ft onto a concrete sur- Drop Resistance face ESD Protection (Air Discharge) 25 kV Humidity (Non-condensing) 5 - 95% Particulate And Water Sealing IP52 Operating: 0 to 40 °C / 32 to 104 °F...
Page 301: Reading Performance
Read Height 14.0 cm / 5.5 in Reading Angle Pitch: +/- 65°; Roll (Tilt): 0 - 360°; Skew (Yaw): +/- 75° Beeper (Adjustable Tone and Volume); Datalogic ‘Green Spot’ Reading Indicators Good Read Feedback; Good Read LED Resolution (Maximum) 0.130 mm / 5 Mils...
Page 302: Utilities
Utilities Utilities Parameter Specification Either Aladdin or Scanalyzer can be used for scanner configura- Aladdin and Scanalyzer tion. Both are available for download at no charge. JavaPOS Utilities are available for download at no charge. OPOS / JavaPOS OPOS Utilities are available for download at no charge. Remote Host Download Lowers service costs and improves operations.
Page 303: Led And Beeper Indicators
LED and Beeper Indicators The scanner’s beeper sounds and its green LED illuminates to indicate various functions or errors on the scanner. The tables below list these indications. The scanner’s functions are programmable, and so may or may not be turned on. For example, certain indications such as the power-up beep can be disabled using programming barcode labels.
Page 304: Error Codes
Error Codes Error Codes If an error is detected, the scanner will sound a long low tone (for three sec- onds) and flash its LED, indicating a failure. When this occurs, press the Scanner Pushbutton to hear the error code. If it is configured to do so, the scanner will sound a series of beeps corresponding to the error code and/or flash its LED simultaneous to the beeps.
Page 305: Appendix B Cable Pinouts
Appendix B Cable Pinouts Standard Cable Pinouts (Primary Interface Cables) Pin # RS-232 USB, USB Keyboard, USB COM, USB-OEM VBUS Product Reference Guide...
Page 306: Appendix C Alpha-Numeric Keypad
Appendix C Alpha-Numeric Keypad Magellan™ 1500i...
Page 307 For numeric entry sequences, the scan- ner will announce the number of digits remaining to be entered after each label NOTE read. Product Reference Guide...
Page 308: Appendix D. Factory Default Settings
Appendix D Factory Default Settings The following table provides a listing of the most common factory settings for the interfaces shown. Some of the individual interfaces listed in the defaults table below appear in the same column since they share similar feature set- tings with few (if any) exceptions....
Page 309 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC OA (10 OA (10 OA (10 OA (10 OA (10 OA (10 Center Zone Size on page 26 percent) percent) percent) percent) percent) percent) Sleep Mode Timer on page 27 5 minutes 5 minutes 5 minutes...
Page 310 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Imaging Features Image Destination on page 49 00 (disable) 00 (disable) (disable) (disable) (disable) (disable) Picture Retrieval Timeout on page 05 (5 sec.) 05 (5 sec.) 05 (5 sec.) 05 (5 sec.) 05 (5 sec.)
Page 311 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC USB OEM Scanner Device Type on 00 (table top) 00 (table top) page 79 00 (disabled 00 (disabled USB OEM Additional Interface upon upon Options on page 80 enumeration) enumeration) RS-232 Baud Rate on page 81...
Page 312 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Global Suffix on page 100 0D00 (CR) 0D00 (CR) 0D00 (CR) 0D00 (CR) 0D00 (CR) 0D00 (CR) AIM ID on page 101 00 (disable) (disable) (disable) (disable) (disable) 01 (Enable as...
Page 313 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC EAN-13 on page 131 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) EAN-13 First Character Transmis- 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable)
Page 314 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC UPC/EAN Stitch Unlike Label 00 (disable) 00 (disable) Halves on page 153 (disable) (disable) (disable) (disable) UPC/EAN Minimum Segment 05 (5 char.) 05 (5 char.) 05 (5 char.) 05 (5 char.) 05 (5 char.) 05 (5 char.)
Page 315 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC DataBar Expanded on page 179 00 (disable) 00 (disable) (disable) (disable) (disable) (disable) DataBar Expanded EAN-128 Emu- 00 (disable) 00 (disable) lation on page 180 (disable) (disable) (disable) (disable)
Page 316 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Code 32 Check Character Transmis- 00 (disable) sion on page 200 (disable) (disable) (disable) (disable) Code 128 on page 201 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable)
Page 317 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Codabar Check Character Trans- 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) 01 (enable) mission on page 222 Codabar Minimum Read on page (1 read) (1 read) (1 read) (1 read)
Page 318 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Standard 2 of 5 Check Character 00 (disable) 00 (disable) Calculation on page 242 (disable) (disable) (disable) (disable) Standard 2 of 5 Check Character 01 (enable) 01 (enable) 01 (enable) 01 (enable)
Page 319 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Set Micro PDF 417 Length 1 on 0001 0001 0001 0001 0001 0001 page 260 Set Micro PDF 417 Length 2 on 016E 016E 016E 016E 016E 016E page 260...
Page 320 RS-232 USB COM Default Feature RS-232 Wincor- Keyboard USB OEM Master Nixdorf USB TEC Planet Code on page 275 00 (disable) 00 (disable) (disable) (disable) (disable) (disable) Royal Mail on page 276 00 (disable) 00 (disable) (disable) (disable) (disable) (disable) Kix on page 277 00 (disable) 00 (disable)
Page 321: Appendix E. Keyboard Function Key Mappings
Appendix E Keyboard Function Key Mappings USB Function Key Usage Map Modifier/ ASCII Key value Usage Name Scancode 00h 44h 00h 45h GUI right Make 80h 00h GUI right Break 00h 00h CTRL right Make 10h 00h CTRL right Break 00h 00h 00h 2Ah TAB right...
Page 322: Scanset 1 Function Key Map
Scanset 1 Function Key Map ASCII ASCII code Key Scancode (hex) ALT left Make ALT left Break CTRL left Make CTRL left Break CTRL right Make E0h 1Dh CTRL right Break E0h 9Dh TAB right RIGHT arrow (inner keypad) 4Dh + E0 TAB left 0Fh + S Enter (inner keypad)
Page 323: Scanset 3, 102-Key Function Key Map
Scanset 3, 102-Key Function Key Map ASCII (hex) ASCII code Key Scancode ALT left Make ALT left Break F0h 19h CTRL left Make CTRL left Break F0h 11h CTRL right Make CTRL right Break F0h 58h TAB right RIGHT arrow (inner keypad) TAB left 0Dh + S Enter (inner keypad)
Page 324: Scanset 3 122-Key Function Key Map
Scanset 3 122-Key Function Key Map ASCII ASCII code Key Scancode (hex) ALT left Make ALT left Break F0h 19h CTRL left (RESET) Make only CTRL left (RESET) Make/Break 11h F0h 11h ONLINE Enter Make only ONLINE Enter Make/Break 58h F0h 58h TAB right RIGHT arrow (inner keypad) TAB left...
Page 325: Japanese Dos Function Key Map
Japanese DOS Function Key Map ASCII value ASCII code Scancode ALT left Make ALT left Break CTRL left Make CTRL left Break CTRL right Make CTRL right Break TAB right RIGHT arrow (inner keypad) TAB left 3Ch + S Enter (right keypad) INSERT (inner keypad) PAGE UP (inner keypad) PAGE DOWN (inner keypad)
Page 326: Nec 9801-Key Function Key Map
NEC 9801-Key Function Key Map ASCII value ASCII code Scancode unused CAPS LOCK ON (make) CAPS LOCK OFF (break) CTRL left Make CTRL left Break CTRL-C TAB right RIGHT arrow (inner keypad) TAB left 0Fh + S DELETE INSERT (inner keypad) KATAKANA LOCK ON (Make) KATAKANA LOCK OFF (Break) HOME (inner keypad)
Page 327: Appendix F Host Commands
Appendix F Host Commands Accepting RS-232 and USB COM Commands The scanner responds to the following RS-232 and USB COM commands: COMMAND ASCII COMMENT Enable Scanner 0x45 Disable 0x44 Scanner Reset Scanner 0x52 Not On File Indication 0x46 Long series of beeps Beep Good Read Tone 0x42 Beeps if Good Read Beep is enabled...
Page 328: Appendix G Sample Symbols
Appendix G Sample Symbols 1D Symbol Samples UPC-A 0 1234567890 Interleaved 2 of 5 1234567890 Code 128 Code 128 EAN-13 9 780330 290951 Code 39 BC321 Codabar A13579B Code 93 123456-9$ Magellan™ 1500i...
Page 329 Code 2 of 5 123456 GS1 DataBar Omnidirectional (01)00123456789012 GS1 DataBar Expanded 0100123456789050 GS1 DataBar Limited (01)16543210987654 Product Reference Guide...
Page 330: 2D Sample Symbols
2D Sample Symbols 2D Sample Symbols PDF 417 A12B3C Micro PDF 417 BV17453 Datamatrix 1314H17LL QR Code 35900G9 Micro QR Code ABCDEF Aztec This is an Aztec Code Magellan™ 1500i...
Page 331: Composite Sample Symbols
Composite Sample Symbols GS1 DataBar Limited Composite GS1 DataBar Truncated Composite Product Reference Guide...
Page 332 Composite Sample Symbols NOTES Magellan™ 1500i...
Page 333: Ascii Character Set
ASCII Character Set The table on this page shows a set of ASCII characters and their corresponding Hex Values. The Hex Values in this table are needed for setting symbology-specific label identifiers, as well as enabling custom prefix and suffix characters. ASCII ASCII ASCII...
Page 334 ©2018-2019 Datalogic S.p.A. and/or its affiliates • All rights reserved. • Without limiting the rights under copyright, no part of this documentation may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Datalogic S.p.A.
