- Page 1 MAGELLAN™ 3410VSi QUICK REFERENCE GUIDE Omni-Directional Imaging Scanner...
- Page 2 Datalogic shall not be liable for technical or editorial errors or omissions contained herein, nor for incidental or consequential damages result- ing from the use of this material. Datalogic reserves the right to change any specification at any time without prior notice.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Features ................1 Installation ............... 3 Wall/Desk Mount ................5 Installation Instructions ............5 Desk (Horizontal) Mounting ............5 Wall (Vertical) Mounting ............6 Attaching/Detaching the Scanner ..........8 Seating the Scanner in the Mount ...........8 Detaching the scanner .............8 Bottom Cover / Tilting Riser............ - Page 4 NOTES MAGELLAN™ 3410VSI...
-
Page 5: Features
MAGELLAN™ 3410VSI Use this guide to quickly complete installation of the Magellan 3410VSi series of bar code readers, and begin using your scanner. For more details and programming information, reference the Product Reference Guide (PRG), which is available for viewing and download from the Datalogic website (www.datalogic.com). - Page 6 Figure 2. Scanner Features - Back View Cable Routing Area Regulatory Label USB Micro B/ MicroSD Card Port (Service Access) Serial Number Label Figure 3. Scanner Features - Bottom View USB Aux Port MicroSD Card USB Micro B Power Host Port Cavity for EAS Connection Wire MAGELLAN™...
-
Page 7: Installation
INSTALLATION Connect the scanner to the host (terminal) using the interface (I/F) cable, as shown in the following figures. A cable from an older existing installation can be re-used for RS-232 interfaces. If external power is used/needed, plug the AC Adapter into the AC wall outlet, then connect it to the unit as shown in Figure 5 on page The USB AUX PORT will only be supported by using a 12V power supply... - Page 8 Figure 5. Powered by AC Adapter RS-232 and USB Cables Powered by AC Adapter To Terminal (PC) Figure 6. USB Cable Type A Power Off the Terminal To Terminal (PC) USB Type A Power Off the Terminal NOTE: This cable (or similar) will not support a USB peripheral.
-
Page 9: Wall/Desk Mount
Wall/Desk Mount The Wall/Desk Mount is an accessory part to which the scanner can be attached. The accessory can be mounted horizontally to a desk, countertop, or table using screws or a gooseneck stand. It can also be mounted vertically to a wall using screws, or to a VESA mount. Installation Instructions Determine the mounting location. -
Page 10: Wall (Vertical) Mounting
Figure 8. Desk Mounting Dimensions ALL UNITS ARE IN MM 92.5 Wall (Vertical) Mounting Figure 9. Wall mount #8 screws 50 mm VESA mount screw holes MAGELLAN™ 3410VSI... - Page 11 Figure 10. Wall (Vertical) Dimensions ALL UNITS ARE IN MM 135.5 132.1 42.5 130.2 QUICK REFERENCE GUIDE...
-
Page 12: Attaching/Detaching The Scanner
Attaching/Detaching the Scanner The scanner attaches or detaches from the Wall/Desk Mount as shown in the illustration below. Seating the Scanner in the Mount Guide the scanner diagonally down, seating the L-Bracket tabs on the Mount into the scanner’s slots. Push the scanner down to snap into place. -
Page 13: Bottom Cover / Tilting Riser
Bottom Cover / Tilting Riser To remove the Bottom Cover, put your finger in the hole and pull it away from the scanner, at an angle. The snaps will disengage on that side and the cover will release from the scanner. Attach the Tilting Riser by snapping into the place of the Bottom Cover. -
Page 14: Mounting The Riser
Mounting the Riser The Adjustable Riser can be mounted to a flat surface using two #8 screws. Figure 13. Mounting the Tilting Riser Figure 14. Tilting Riser Dimensions ALL UNITS ARE IN MM 23.8 64.2 MAGELLAN™ 3410VSI... -
Page 15: How To Scan
HOW TO SCAN Bar codes can be presented to the scanner’s window or pushed past it using a “sweep” technique. The scanner can also be programmed to ini- tiate a scan of a cell phone or other LCD bar code object, or an image capture upon pushing the Camera Button. -
Page 16: Camera Button
PRESS FUNCTION COMMENT DURATION Press the button momentarily to increase speaker volume. When the loudest volume is reached, a repeated press of the Momentary (when Increments volume button cycles volume back to scanner is awake) the lowest setting, then volume increases on subsequent press(es). -
Page 17: Led And Beeper Indicators
LED AND BEEPER INDICATORS The scanner’s beeper sounds and its green LED illuminates to indicate various functions or errors on the scanner. The tables that follow list these indications. An exception is that the scanner’s functions are programmable, and may or may not be turned on. For example, some indications (such as the power-up beep) can be disabled using programming bar code labels. -
Page 18: Beeper Indicators
Beeper Indicators BEEPER INDICATION COMMENT The Power-On LED indication is a configurable feature which can be enabled or disabled. When enabled, this beep Power On Beep Single beep indicates the scanner has finished all its power-up tests and is now ready for operation. -
Page 19: Error Codes
PROBLEM SOLUTION If the scanner still does not function properly, consult the Product Reference Guide (PRG) or contact your local supplier or Datalogic Customer Support Services. a. Reading of the various bar code symbologies can be independently enabled or disabled in the scanner. -
Page 20: Programming
Programming Mode and return the scanner to normal operation. Select other options and customize your scanner with programming barcodes available in the PRG, or use the Datalogic Scanalyzer utility available on the Datalogic website. NOTE: In the following sections, text shown with a green star indicates a factory default value. - Page 21 START / END 000145(CR) USB-OEM 000135(CR) USB Keyboard 000147(CR) USB COM Interface NOTE: Reference the Product Reference Guide (PRG) or Datalogic Scanalyzer utility for additional options. QUICK REFERENCE GUIDE...
-
Page 22: Imaging Features
Imaging Features See the PRG for more information on these features. Camera Button Mode Scan one of the bar codes below to enable or disable the camera button. START / END Camera Button Mode = Disable Camera Button Mode = Enable MAGELLAN™... -
Page 23: Image Destination
Image Destination Specifies the destination for pictures/images taken with a camera button press. START / END 042501\r 500(CR) Image Destination = Disable Image Destination = SD card 042503\r Image Destination = Host port QUICK REFERENCE GUIDE... -
Page 24: Cell Phone Mode
Cell Phone Mode Enables/disables mobile phone barcode reading. START / END 046700(CR) Cell Phone Mode = Enable (Toggle) 046702(CR) Cell Phone Mode = Enable (Always On) 046701(CR) Cell Phone Mode = Enable (Timer Expiration) MAGELLAN™ 3410VSI... -
Page 25: Cell Mode Percent
Cell Mode Percent Specifies the rate of frames dedicated to reading cell phones. Cell phone mode must be enabled for this to be active. NOTE: Settings above 10% will slow down read performance on printed barcodes. START / END 047100(CR) ... -
Page 26: Cleaning
CLEANING Exterior surfaces and scan windows exposed to spills, smudges or debris accumulation require periodic cleaning to assure best performance during scanning. Use a clean, lint-free cloth or paper towel dampened with a nonabrasive, mild, water-based cleaner to wipe away stains, smudges, fingerprints, spills, etc. -
Page 27: Manufacturer Approved Cleaning Materials
Manufacturer Approved Cleaning Materials Datalogic recommends the use of the following cleaners on its products. APPROVED CLEANERS • Hydrogen Peroxide (not to exceed a 3% solution) • Chlorine bleach (not to exceed a 0.25% solution) • Mild detergent and water •... -
Page 28: Warranty
Warranty Period. Products are sold on the basis of specifications applicable at the time of manufacture and Datalogic has no obligation to modify or update Products once sold. The Warranty Period shall be three years from the date of shipment by Datalogic, unless otherwise agreed in an applicable writing by Datalogic. -
Page 29: Going Green
GOING GREEN Thank you for using the bar code mask on the opposite side of this page. This manual has been formatted to minimize the quantity of pages needed to provide the programming bar codes available for this product. QUICK REFERENCE GUIDE... -
Page 30: Bar Code Mask
BAR CODE MASK Cut a hole in this page and remove it from the manual as indicated to create a sleeve through which bar codes can be individually viewed and scanned. It is important that only one bar code at a time be presented to the scanner. - Page 32 ©2020 Datalogic S.p.A. and/or its affiliates • All rights reserved • Without limiting the rights under copyright, no part of this docu- mentation may be reproduced, stored in or introduced into a retrieval system, or transmitted in any form or by any means, or for any purpose, without the express written permission of Data- logic S.p.A.
