Xerox Phaser 3330 Service Manual page 73

Troubleshooting
LEVEL 1 LEVEL 2
Copier dc330 Component Control
Diagnostics (con't)
(con't)
2-14 Phaser 3330 and WorkCentre 3335/3345
Service Manual
LEVEL 3
07-300 Tray3 Home Position
07-310 T3 Paper Empty Sensor
07-320 T3 size1 sensor
07-330 T3 size2 sensor
07-340 T3 size3 sensor
07-350 T3 Stack Height Sensor
07-360 T3 Paper Low Sensor
07-400 Tray4 Home Position
07-410 T4 Paper Empty Sensor
07-420 T4 size1 sensor
07-430 T4 size2 sensor
07-440 T4 size3 sensor
07-450 T4 Stack Height Sensor
07-460 T4 Paper Low Sensor
07-510 Bypass Paper Empty Sensor
08-100 Feed Sensor
08-200 T2 Feed Sensor (or Door Open)
08-300 T3Feed Sensor (or Door Open)
08-400 T4 Feed Sensor (or Door Open)
08-500 Regi. Sensor
08-600 Fuser Exit Sensor
08-700 Duplex Jam1 Sensor
08-710 Duplex Jam2 Sensor
09-100 MHV Bias
09-110 MHV Bias Read
09-200 Dev Bias
09-300 THV(+) Bias
09-400 THV(-) Bias
09-310 THV Bias Read
09-800 Deteck Bias
