Xerox Phaser 3330 Service Manual page 72

LEVEL 1 LEVEL 2
Copier dc330 Component Control
Diagnostics (con't)
(con't)
Xerox Internal Use Only
LEVEL 3
09-510 SMPS Fan Run Ready
08-800 Bypass Feed Solenoid (Clutch)
08-810 T1 Pick-Up Solenoid (Clutch)
08-820 T2 Pick-Up Solenoid (Clutch)
08-830 T3 Pick-Up Clutch
08-840 T4 Pick-Up Clutch
08-850 Registration Clutch
08-860 Duplex Feed Clutch
08-870 Duplex Gate Solenoid
08-920 T2 Feed Motor Run
08-930 T3 Feed Motor Run
08-940 T4 Feed Motor Run
01-100 Side Cover Interlock
01-200 Exit Cover Present Sensor
08-720 Out-Bin Full Sensor
07-100 Tray1 Home Position
07-110 T1 Paper Empty Sensor
07-120 T1 size1 sensor
07-130 T1 size2 sensor
07-140 T1 size3 sensor
07-150 T1 Stack Height Sensor
07-160 T1 Paper Low Sensor
07-200 Tray2 Home Position
07-210 T2 Paper Empty Sensor
07-220 T2 size1 sensor
07-230 T2 size2 sensor
07-240 T2 size3 sensor
07-250 T2 Stack Height Sensor
07-260 T2 Paper Low Sensor
