Xerox Phaser 3330 Service Manual page 112

Tray 1 Empty
The paper has run out in Tray 1.
Applicable Error
• 07-110: Paper Empty at Tray 1
Initial Actions
• Load paper in Tray 1.
• If problem persists use the following procedure.
Troubleshooting Reference Table
Applicable Parts
• Paper Empty Sensor, (PL 3.1A.20,
List 3.1A Frame (2 of
• Main Board: Phaser 3330 (PL 1.0.7,
List 1.0 Phaser 3330
3335 and 3345 (PL 6.1.7,
WorkCentre 3335/3345
Troubleshooting Procedure Table
Step Actions and Questions
1. Enter dC330 Component
07-110 to check the Paper Empty Sensor
and Paper Empty Actuator.
The display changes when the sensor is
actuated?
2. Check that the sensor and actuator are
correctly installed and undamaged.
The sensor and actuator are good?
3. Install a new Paper Empty Sensor (PL 3.1A.
20, Parts List 3.1A Frame (2 of
Note: refer also to (PL 3.1A .17,
3.1A Frame (2 of
sensor.
If necessary, install a new Tray 1 Empty
Actuator, (PL 3.1A.17,
(2 of 2)).
Does the error persist?
Xerox Internal Use Only
Wiring and Plug/Jack Map Reference
Parts • Phaser 3330 Main PWB Connector Designators
2)).
• Phaser 3330 Control Panel PWB
Parts
• Wiring Diagrams for P3330/WC3335/WC3345
Main) WorkCentre
• WorkCentre 3335/3345 Main PWB Connector Designators
Parts List 6.1
• DADF PWB
Main).
• SMPS PWB
Control, code
2)).
Parts List
2)) to identify the correct
Parts List 3.1A Frame
Yes
Go to step 4.
Go to step 3.
Go to step 3.
Phaser 3330 and WorkCentre 3335/3345
Troubleshooting
No
Go to step 2.
Go to step 3.
Complete.
