Figure 3-1. ADSP-BF534 Memory Map

ADSP-BF537 Blackfin Processor Hardware Reference

ADSP-BF534 MEMORY MAP

CORE MMR REGISTERS (2M BYTE)

SYSTEM MMR REGISTERS (2M BYTE)

SCRATCHPAD SRAM (4K BYTE)

INSTRUCTION SRAM/CACHE (16K BYTE)

INSTRUCTION BANK B SRAM (16K BYTE)

INSTRUCTION BANK A SRAM (32K BYTE)

DATA BANK B SRAM/CACHE (16K BYTE)

DATA BANK B SRAM (16K BYTE)

DATA BANK A SRAM/CACHE (16K BYTE)

DATA BANK A SRAM (16K BYTE)

BOOT ROM (2K BYTE)

ASYNC MEMORY BANK 3 (1M BYTE)

ASYNC MEMORY BANK 2 (1M BYTE)

ASYNC MEMORY BANK 1 (1M BYTE)

ASYNC MEMORY BANK 0 (1M BYTE)

SDRAM MEMORY (16M BYTE - 512M BYTE)
