4.4 LAN Interface

When connect PC through LAN interface, the following is required to use the
LAN interface. The LAN interface complies with the LXI standard.
•
•
The user can view the related information of LAN interface or configure the
communication parameters in system menu.
View LAN Interface Information
The operation steps to view the LAN interface information are as follows.
1. Press [Shift]+[P-set](Menu) to enter into the system menu interface.
2. Use left and right keys or rotate the voltage knob to select SYSTEM and
3. Use left and right keys or rotate the voltage knob to select Communication
4. Use left and right keys or rotate the voltage knob to select LAN and press
5. Press [Enter]key to confirm.
6. Use left and right keys or rotate the voltage knob to review the LAN interface
7. After setting, press [Esc] to exit.
Configure LAN Interface Information
The configurable parameters are described as follows.
The instrument address
•
•
When using one crossover cable to connect PC directly, the gateway address
should be consistent with that of the PC, and the IP address should be at the
same network segment with the PC's IP address.
When the instrument and computer are connected to the router, an independent
IP address must be assigned for the instrument.
press [Enter] key to confirm.
and press [Enter]key to confirm.
[Enter]key to confirm.
The first displayed menu item Info is to view the LAN interface information.
information, Refer to3.9 System Menu
IP Addr: This value is the Internet Protocol (IP) address of the instrument.
An IP address is required for all IP and TCP/IP communications with the
instrument. An IP Address consists of 4 decimal numbers separated by
periods. Each decimal number ranges from 0 through 255 with no leading
zeros (for example, 169.254.2.20).
Sub Net: This value is used to enable the instrument to determine if a client
IP address is on the same local subnet. The same numbering notation
applies as for the IP Address. When a client IP address is on a different
subnet, all packets must be sent to the Default Gateway.
Copyright © Itech Electronic Co., Ltd.
for more information.
