2.5.2 LAN Interface

When the user connect PC through LAN interface, the following is required to
use the LAN interface. The LAN interface complies with the LXI standard.
Connect Interface
Use the following steps to quickly connect your instrument to your LAN and con-
figure it. Two typical LAN interface systems are described below: private LAN
and site LAN.
•
•
•
•
View LAN Interface Information
The operation steps to view the LAN interface information in the System Menu
are as follows.
1. Press the composite keys [Shift]+[P-set] (System) on the front panel to en-
2. Rotate the knob to select I/O and press [Enter].
3. Press the Left/Right key to select LAN and press [Enter].
4. Press the Left/Right key to select Info and press [Enter].
5. Rotate the knob to view the LAN parameters. See the information in
Connect to the private LAN
A private LAN is a network in which LAN-enabled instruments and com-
puters are directly connected. They are typically small, with no centrally-
managed resources. When connected to a computer, a standard network
cable can be used to connect directly to the computer via the LAN interface.
Connect to the site LAN
A site LAN is a local area network in which LAN-enabled instruments and
computers are connected to the network through routers, hubs, and/or
switches. They are typically large, centrally-managed networks with services
such as DHCP and DNS servers. When connected to a computer, a network
cable can be used to connect to the router, and the computer is also con-
nected to the router.
When using one crossover cable to connect PC directly, the gateway address of
the instrument should be consistent with that of the PC, and the IP address
should be at the same network segment with the PC's IP address.
When the instrument and computer are connected to the router, an independent
IP address must be assigned for the instrument.
ter the system menu.
tem Menu Function for details.
