Taski Swingo 455B Technical Manual page 92

GTS
Pos. Plug
1 B1
1 B1
2 S3
2 S3
2 S3
3 X7
3 X7
3 X7
3 X7
3 X7
3 X7
3 X7
3 X7
Table 3: Charger connector description
5. March 2013
Copyright © 2013, Diversey Inc.
06.20.21 charger - connections - 455B_755B eco_755B power 855B power_V1.00.fm
Description [plug]
Battery charge (red)
Battery charge (black)
Power main cord
Power main cord
Power main cord
Charger communication
Charger communication
Charger communication
Charger communication
Charger communication
Charger communication
Charger communication
Charger communication
Edition: V1.10/2013
Pin Description [pin]
1 Battery charge - Plus (+)
2 Battery charge - Minus (-)
1 Phase
2 Neutral
3 GND
1 Not connected
2 Not connected
3 Emergency loop IN
4 Emergency loop OUT
5 GND
6 Information charge failed
7 Information charge
8 Information charged
Technical Manual
6-17
