GTS
Picture 15: Sustaining disc
•
•
•
•
Adjustment
Tighten the 6 screws with 15 Nm.
•
•
5. March 2013
Copyright © 2013, Diversey Inc.
Mount the articulation onto the tank.
Position the two cover discs.
Mount the 6 screws.
Mount the handle cover according to chapter MOUNTING OF
HANDLE COVER AND ELECTRONICS.
Mount the tank cover.
Connect the two flexible hose on to the tank cover.
Edition: V1.10/2013
Technical Manual
5-14
