GTS
6.2
Dashboard
6.2.1
Removing of dashboard
Picture 1: Dashboard
•
•
Be cautious when removing the dashboard as you can damage the
wires or the ribbon cables of the dashboard.
5. March 2013
Copyright © 2013, Diversey Inc.
Remove handle cover according to chapter REMOVING OF
HANDLE COVER AND ELECTRONICS in the mechanical section.
Remove the dashboard foil (01/111).
Edition: V1.10/2013
Technical Manual
6-3
