Taski Swingo 455B Technical Manual page 68

GTS
Picture 72: Brush drive setting RH
•
•
•
Do not use the locking lever (455B:06/116, 755B:07/116) to tighten
the eccentric shaft (455B:06/110, 755B:07/110).
•
Connect the wires of the brush motor and the cable strand matching
the colours.
•
•
•
•
5. March 2013
Copyright © 2013, Diversey Inc.
Position a new self locking nut (M6) at the eccentric disc.
Position two new self locking nuts (M8) at the bold and the
eccentric shaft.
Tighten all self locking nuts.
Connect the brush motor to the connection block.
Connect the fresh water hose to the brush drive unit.
Position the brush housing on the brush drive unit.
Position the brush housing screws and tight them.
Close and lock battery compartment and lock it with the screws
of the looking system.
Edition: V1.10/2013
Technical Manual
5-47
