GTS
5.1
Handle
5.1.13 Mounting of articulation
Picture 22: Articulation
•
•
•
•
•
•
5. March 2013
Copyright © 2013, Diversey Inc.
Mount the guide bar.
Mount the articulation.
Mount the screw from the handle housing.
Mount the bowden cable according to chapter MOUNTING OF
BOWDEN CABLE.
Mount the toothrockers according to chapter MOUNTING OF
TOOTHROCKER.
Mount the handle cover according to chapter MOUNTING OF
HANDLE COVER AND ELECTRONICS.
Edition: V1.10/2013
Technical Manual
5-19
