GTS
5.6
Squeegee
5.6.5
Removing of back blade old setup
Picture 46: Back blade position
•
Picture 47: Back blade fixation
•
Picture 48: Remove back blade
5. March 2013
Copyright © 2013, Diversey Inc.
Untighten the fixation screws (455 & 755E:05/111, 755B:04/
111) on both sides to release the pressure of the tightening
strap and remove it.
Remove back blade.
Edition: V1.10/2013
Technical Manual
5-34
