GTS
5.1
Handle
5.1.3
Removing of switch lever
Picture 5: Switch lever
•
•
•
You can only remove both switch levers together.
Remarks
Both levers are the same spare part.
5. March 2013
Copyright © 2013, Diversey Inc.
Remove handle cover according to chapter REMOVING OF
HANDLE COVER AND ELECTRONICS.
Remove screw (01/102) for left switch lever and screw (01/102)
for right switch lever.
Remove the switch levers (01/114).
Edition: V1.10/2013
Technical Manual
5-5
