5.9 Brush drive
5.9.8 Mounting of motor & motor belt
e
Picture 82: Brush motor belt mount
•
Take care that the belt is positioned correctly.
•
•
Service
Apply adhesive looking (09/138) on the screws (09/134).
•
•
•
•
•
5. March 2013
Copyright © 2013, Diversey Inc.
Position the new motor/new belt.
Insert the counter head screw.
Position the two other screws.
Tension the belt.
Tighten all screws.
Complete assembling according to the chapter MOUNTING OF
PULLEY - NEW SETUP/OLD SETUP.
Complete assembling according to the chapter MOUNTING OF
BRUSH BELT - NEW SETUP/OLD SETUP.
Complete assembling according to the chapter MOUNTING OF
BRUSH DRIVE UNIT.
