GTS
5.6
Squeegee
5.6.9
Removing of back blade new setup
Picture 56: Squeegee new setup
•
•
Picture 57: Star knob
•
Picture 58: Back blade
5. March 2013
Copyright © 2013, Diversey Inc.
Remove the two star knobs (455 & 755E: 05/108, 755B & 855:
04/108).
Press out the squeegee inlet (455 & 755E: 05/124, 755B & 855:
04/124).
Remove back blade (455: 05/122, 755B: 04/122, 755E: 05/108,
855: 05/122) by tearing it off from the squeegee inlet.
Edition: V1.10/2013
Technical Manual
5-38
