Dashboard
Picture 3: Dashboard
6.2.1.1 Replacing of dashboard
Remove
•
•
•
Mount
•
•
•
15. March 2010
Copyright © 2010, Diversey Inc.
Remove the 5 screws of the dashboard.
Dismount dashboard from machine.
Disconnect all electrical connections.
Connect electrical connections to dashboard.
Mount dashboard on machine.
Fix the dashboard with the 5 screws to the machine.
Edition: V1.00/2010
Technical Manual
6-4
