L A
INK GGREGATION
Table 4-52 show lacp internal - display description
Field
LACP Port
Priority
Admin State,
Oper State
4-198
C
OMMANDS
Description
LACP port priority assigned to this interface within the channel
group.
Administrative or operational values of the actor's state
parameters:
• Expired – The actor's receive machine is in the expired state;
• Defaulted – The actor's receive machine is using defaulted
operational partner information, administratively configured for
the partner.
• Distributing – If false, distribution of outgoing frames on this
link is disabled; i.e., distribution is currently disabled and is not
expected to be enabled in the absence of administrative changes
or changes in received protocol information.
• Collecting – Collection of incoming frames on this link is
enabled; i.e., collection is currently enabled and is not expected
to be disabled in the absence of administrative changes or
changes in received protocol information.
• Synchronization – The System considers this link to be
IN_SYNC; i.e., it has been allocated to the correct Link
Aggregation Group, the group has been associated with a
compatible Aggregator, and the identity of the Link Aggregation
Group is consistent with the System ID and operational Key
information transmitted.
• Aggregation – The system considers this link to be aggregatable;
i.e., a potential candidate for aggregation.
• Long timeout – Periodic transmission of LACPDUs uses a slow
transmission rate.
• LACP-Activity – Activity control value with regard to this link.
(0: Passive; 1: Active)
(Continued)
