2.11.1

The PTP Screen

The PTP screen provides PTP status information, and provides access to all configurable
PTP settings.
To access the PTP screen, navigate to
PTP screen will open:
Figure 2-10:
For each Ethernet port (ETH0-ETH3) you can toggle PTP functionality
You can also access the "Settings" panel and the "Statistics" panel for each port (see
below).
2.11.1.1 The PTP Settings Panel
The Settings Panel provides access to the configuration settings, divided into three
tabs, which are described below. Each tab allows you to
CHAPTER 2 • VelaSync User's Manual Rev. 3
VelaSync PTP screen
Note: The Restore Defaults
restore ALL the factory defaults for ALL Ethernet ports.
MANAGEMENT > NETWORK: PTP
Restore
button in each PTP Settings panel will
2.11 Configuring PTP
Setup. The
ON or OFF.
defaults.
87
