Status Monitoring via the System Monitor Screen
To display status information pertaining mainly to VelaSync's current hardware status,
navigate to
The information provided on the
els:
System Status panel
This is identical with the HOME screen
Disk Status panel
This panel displays:
Total: [MB]
Used: [MB]
Free: [MB]
Percent: [%]
The last item refers to system storage. If you need to update the System Software, and
this number is
up memory space. (Navigate to
responding buttons in the lower left-hand corner.)
System Monitor panel
Graphs are displayed for:
Board Temperature
CPU Temperature
Memory Used
CPU Used.
To delete the logged data used to generate the displayed graphs, click the TRASHCAN
icon. (Note that re-populating the graphs with fresh data generated at a 1/min. rate will
take several minutes.)
To download the logged data in .csv format, click the ARROW icon.
4.7.1.2 Ethernet Monitoring
To monitor Ethernet status and traffic:
190
TOOLS > SYSTEM > System
System Monitor
70% or higher, it is recommended to clear logs and stats in order to free
TOOLS > SYSTEM:
Monitor.
Screen is subdivided into three pan-
"System Status panel" on
Upgrade/Backup, and click the cor-
