1.4.2.2 Communication Ports
2x 10 GbE
2x 1GbE
1x IPMI (V.2.0)
1x RS-232 (Fast UART)
4x USB 2.0
1x VGA
1.4.3

Environmental Specifications

1.4.4 Size, Weight & Power
For additional hardware specifications, see the User's Manual of the Original Equipment
Manufacturer:
https://www.supermicro.com/manuals/superserver/1U/MNL-1771.pdf
1
Please inquire about availability.
CHAPTER 1 • VelaSync User's Manual Rev. 3
Amplitude: TTL compatible, 4.3 V
[PCIe only: 2.2 V minimum, base-top-peak into high impedance]
Pulse width: 50 ns to 999 ms active pulse width, in 20 ns increments
Period: 100 ns min, 60 s max, in 20 ns increments
Polarity (selectable): Positive or negative
Time-Match/Alarm Output
Amplitude: TTL compatible, 4.3 V minimum, base-to-peak into 50 Ω; 2.2 V
minimum, base-to-peak into high-impedance
Range: 100 days in 5 ns steps
SFP+ (optionally 4x, or 2x 10 Gb plus 2x 40 Gb
RJ-45 with hardware time stamping
Operation: 10°C to 35°C, RH: 8 to 90% (non-condensing @ 35°C)
Storage: –40°C to +50°C , RH: 5 to 95% (non-condensing @ 35°C)
Dimensions: (WxHxD) 437 x 43 x 650 mm (17.2 x 1.7 x 25.6 in.)
Weight: 23.5 lbs. (10.7 kg)
AC input: 100 - 240 V
RMS
, base-to-peak into 50 Ω
min
, 50 - 60 Hz, 6.1 - 2.6 A
1.4 Technical Specifications
