4. To apply your changes, click
CHAPTER 2 • VelaSync User's Manual Rev. 3
Static IPv4
Address: This is the unique address assigned by the network
administrator.
Table 2-8:
Default IP addresses
Default "static lease"
ETH port
IP address
ETH0
192.168.1.1
ETH1
defaults to DHCP
ETH2
defaults to DHCP
ETH3
defaults to DHCP
The default subnet is: 255.255.0.0
Netmask: This is the network subnet mask assigned by the network admin-
istrator. In the form "xxx.xxx.xxx.xxx." See
page 35
for a list of subnet mask values.
IPv4 Gateway
: The gateway (default router) address is needed if com-
munication to the VelaSync is made outside of the local network. By
default, the gateway is disabled.
Domain: This is the domain name to be associated with this port.
DNS
Primary: This is the primary DNS address to be used for this port.
Depending on how your DHCP server is configured, this is set automatically
once DHCP is enabled. Alternatively, you may configure your DHCP server
to NOT use a DNS address. When DHCP is disabled, DNS Primary is set
manually, using the format "#.#.#.#" with no leading zeroes or spaces,
where each '#' is a decimal integer from the range [0,255].
DNS
Secondary: This is the secondary DNS address to be used for this
port. Depending on how your DHCP server is configured, this is set auto-
matically once DHCP is enabled, or your DHCP server may be configured
NOT to set a DNS address. When DHCP is disabled, DNS Secondary is set
manually, using the format "#.#.#.#" with no leading zeroes or spaces,
where each '#' is a decimal integer from the range [0,255].
MTU: Maximum Transmission Unit. Range (for Ethernet v2): Default: 1500
bytes. Smaller packages are recommended, if encapsulation is required e.g.,
to meet encryption needs, which would cause the maximum package size
to be exceeded.
Submit
2.9 Configuring Network Settings
"Subnet Mask Values" on
(the window will close), or Apply.
47
