2.11 Configuring PTP
2.11.1.2 The PTP Statistics Panel
This panel provides statistics for each Ethernet port. If the PTP is set to OFF for a spe-
cific port, this screen will not display any information.
All statistics shown are based on the traffic that is detectable by VelaSync, i.e. in a
Unicast environment, VelaSync may only detect traffic that is addressed to it, based on
switch configuration.
Figure 2-12:
PTP
Clock
Domain: Domain number of the selected PTP node.
Unicast: [0,1] OFF or ON (1)
Last
Average
message has been detected (in seconds e.g., "1.0" would mean once every
second).
2.11.2

Enabling/Disabling PTP

To enable or disable PTP:
1. Navigate to
2. In the
port.
90
PTP Statistics Panel
Node: IP address of PTP node.
Identity: [e.g., "a0:36:9f:ff:fe:37:b9:5d"]
Time: [e.g., "2016-08-12 18:19:15"] The last time a packet was received.
Rate: [e.g., "0.0624986091344933"] Indicates how often the selected
MANAGEMENT > NETWORK: PTP
PTP panel, slide the toggle switch to ON or OFF for the desired Ethernet
Setup.
