2.8 Advanced Timing Connections
2.8.1.1

Timing Interface Adapter Cable

VelaSync is shipped with a 15 cm (6") adapter cable that is used to connect the micro
25-pin timing interface connector on the card to the breakout cable:
Figure 2-7:
Table 2-2:
PIN-1
PIN-2
PIN-3
PIN-4
PIN-5
PIN-6
PIN-7
PIN-8
PIN-9
PIN-10
PIN-11
PIN-12
36
Adapter cable
Adapter pinout, timing connector
END "A"
PIN-1
PIN-2
PIN-3
PIN-4
PIN-5
PIN-6
PIN-7
PIN-8
PIN-9
PIN-10
PIN-11
PIN-12
END "B"
