Spectracom VelaSync 1232 User Manual page 53

Pin
2
3
4
5
1
1
1
1
1
1
2
3
4
6
1
2
3
4
6
CHAPTER 2 • VelaSync User's Manual Rev. 3
Signal
IRIG DCLS I/O (DB-9 Female)
Ground
Ground
IRIG DCLS Input +
IRIG DCLS Input -
P3—10MHz Output (BNC Female)
10 MHz Output
P4—1PPS Output (BNC Female)
1PPS Output
P5—IRIG AM Input (BNC Female)
IRIG AM Input +
P6—IRIG AM Output (BNC Female)
IRIG AM Output
P7—1PPS Input (BNC Female)
External 1PPS Input
P8—GP Input (DB-9 Female)
GPIO Input 0
GPIO Input 1
GPIO Input 2
GPIO Input 3
Ground
P9—GP Output (DB-9 Female)
GPIO Output 0
GPIO Output 1
GPIO Output 2
GPIO Output 3
Ground
2.8 Advanced Timing Connections
Pin Signal
6 IRIG DCLS Output +
7 IRIG DCLS Output –
BS Ground
BS Ground
BS Ground
BS IRIG AM Input –
BS Ground
BS Ground
7 Ground
8 Ground
9 Ground
BS Ground
7 Ground
8 Ground
9 Ground
BS Ground
41
