6. The unit is shipped with one
7. To connect a device using DHCP, connect to an Ethernet port without a static IP
8. Log on to the Web UI (see directions in
For more detailed information on network setup, see the section on
work Settings" on page 43
2.6 Accessing the Web UI
VelaSync's Web UI is the recommended tool to interact with the device, since it
provides access to nearly all configurable settings, and obtain comprehensive status
information without having to use the Command Line Interpreter (CLI).
You can access the Web UI either by using the manually set static IP address
192.168.1.1), or by using the DHCP IP address automatically assigned during zero config
setup.
1. Log into the Web UI as an administrator.
CHAPTER 2 • VelaSync User's Manual Rev. 3
ETH0, using the default static IP address (see step 6),
ETH1-ETH5, using a DHCP network (see step 7),
via the serial port (see
page 33).
municate with the Web UI using this address, connect a PC with a configured
LAN port via Ethernet cable to the VelaSync server using ETH0.
address (any Ethernet port except ETH0). Find the unit on your network by con-
tacting your network administrator, and log in to the unit's assigned IP address.
9.
Note: You'll likely want to change the default IP address of the
ETH ports you plan on using. This procedure is described in the
next topic . (You will need an
modem cable
Note: The default login credentials are:
User name =
Password = admin123
"Setting Up an IP Address via the Serial Port" on
static IP address: ETH0 =
"Accessing the Web UI"
Ethernet cable
for this.)
spadmin
2.6 Accessing the Web UI
192.168.1.1. To com-
below).
, or a serial null
"Configuring Net-
(ETH0 =
