2.9 Configuring Network Settings
2.9.2

Network Ports

Ports act as communication endpoints in a network. The hardware configuration of your
unit will determine which ports (e.g., Eth0, Eth1, ...) are available for use. Before using a
port, it needs to be enabled and configured.
To enable & configure, or view a network port:
1. Navigate to
2. The
and their connection STATUS:
3. If the port is not already enabled, in the
click the
expand to show the options needed to complete the port setup.
Fill in the fields as required:
46
MANAGEMENT > NETWORK: Network
Ports panel on the right side of the screen lists the available Ethernet ports,
Green: CONNECTED (showing the connection speed)
Yellow: CABLE UNPLUGGED
attached)
Red: DISABLED.
Locate the port you want to configure and click the GEAR button to enable
& configure the port, or the INFO button to view the port status.
Enable check box. The
Enable eth0: [Checkbox]
Enable DHCPv4: [Checkbox] Check this box to enable the delivery of IP
addresses from a DHCP Server using the DHCPv4 protocol.
Setup.
(the port is enabled but there is no cable
Edit Ethernet Ports Settings
Edit Ethernet Ports Settings
CHAPTER 2 • VelaSync User's Manual Rev. 3
window,
window will
