3.3.3.3 Selecting a GNSS Receiver Mode
When connected to a GNSS antenna that receives a GNSS signal, VelaSync can use
GNSS as an input reference. The factory default configuration allows GNSS satellites to
be received/tracked with no additional user intervention required.
However, there are several user-configurable GNSS settings:
CHAPTER 3 • VelaSync User's Manual Rev. 3
®
M8T
dates: Since 2016
Client A-GPS option: Yes
Server A-GNSS option: Yes
Resurvey: Automatic, after being moved and rebooted — can be changed, see
"Setting GNSS Receiver Dynamics" on
Multi-GNSS reception: Yes, within these permissible settings:
GPS Galileo GLONASS
X X –
X X X
X X –
X – X
X – –
– X X
– X –
– – X
Note: The augmentation systems SBAS and QZSS can be
enabled only if
page 132.
Beidou
–
–
X
–
X
–
X
X
GPS operation is configured.
