3.3 Managing References
Manufacturer/Model: The manufacturer and/or model of the GNSS receiver in
your VelaSync unit.
Validity: Status indicator lights for
a valid signal, "Off" (red) indicates that no valid signal is available. A
light indicates that the monitored 1PPS value fell below a quality threshold and
the unit is in flywheel mode.
Receiver Mode:
Receiver
ics" on
Survey
Number of Tracked
Offset: As set by the user, in nanoseconds.
Antenna
Position: VelaSync's geographic position by:
Receiver
Client A-GPS
Client A-GPS
Server A-GNSS
DISABLED
Server A-GNSS
ents, or it is UNAVAILABLE
126
Single Satellite: Used in areas with poor GNSS reception.
Standard: Default operating mode for the GNSS receiver.
Mobile: For non-stationary applications.
Dynamics: (u-blox receivers only); see
page 132.
Progress: Real-time status:
ACQUIRING (x Satellites)—red
SURVEYING (x %)—yellow; remains at 1% if no satellites are in view
COMPLETE—green
Satellites: The number of satellites currently being tracked.
Sense:
OK (green)
Open: Check the antenna for the presence of an open.
Short: Check the antenna for the presence of a short circuit.
Latitude: In degrees, minutes, seconds
Longitude: In degrees, minutes, seconds
Altitude: In meters MSL (Mean Sea Level)
Constellation: GPS/GLONASS/Galileo/BeiDou/QZSS
Status: A-GPS is ENABLED and running, or DISABLED
Data: External A-GPS data is AVAILABLE, or UNAVAILABLE
Status: The Rinex Server feature is ENABLED and running, or
Data: A-GPS data is AVAILABLE and can be downloaded by cli-
TIME and 1PPS signals: "On" (green) indicates
"Setting GNSS Receiver Dynam-
CHAPTER 3 • VelaSync User's Manual Rev. 3
yellow 1PPS
