2.8.1.2 Basic Breakout Cable
The basic breakout cable breaks out a subset of features from the 26-pin timing con-
nector to separate BNC and DB-9 connectors for use. The basic breakout cable sup-
ports the following features: External 1PPS Input, IRIG AM Input, IRIG DCLS Input, IRIG
AM Output, (1) GP Input, (2) GP Outputs.
