1.5.3

Hard Disk Drives

Each hard disk drive (HDD) carrier has two LEDs:
To release a hard disk drive carrier, in order to remove the hot-swappable hard disk
drive, push the red button for the carrier to release the lever, then pull the carrier out,
using the lever.
For additional instructions on how to replace a hard disk, see
Hard Disk Drive" on
CHAPTER 1 • VelaSync User's Manual Rev. 3
HDD: IDE channel activity when flashing yellow
Power: Power is applied to power supplies (bright green)
Green LED: Indicates drive activity, when illuminated.
Red LED:
When blinking, the drive is rebuilding.
When solid, indicates drive failure (you should also receive an automatic
message from your system management software).
page 164.
1.5 Front Panel Overview
"Removing/Installing a
11
