4.7 Quality Management
Status Monitoring via the HOME Screen
The HOME
"The Web UI HOME Screen" on
The HOME
System Status panel
Reference—Indicates the status of the current synchronizing reference, if any.
Power—Indicates whether the power is on.
Status—Indicates the status of the network's timing. There are three indicators
in the Status field:
Alarm
NTP—Current STRATUM status of this VelaSync unit.
188
screen of the VelaSync Web UI provides a system status overview (see also
page 13).
screen is divided into four
Sync—Indicates whether VelaSync is synchronized to its selected input ref-
erences.
Green indicates VelaSync is currently synchronized to its references.
Orange indicates VelaSync is not currently synchronized to its ref-
erences.
Hold—When lit, VelaSync is in Holdover mode.
Fault—Indicates a fault in the operation of the VelaSync. See
"Troubleshooting via Web UI Status Page" on page 210
troubleshooting faults.
Status: If a major or minor alarm is present, it will be displayed here.
panels:
