1.5 Front Panel Overview
1.5

Front Panel Overview

Figure 1-2:
1.5.1

Control Buttons

UNIT ID
activate via IPMI) to turn the blue "i" LED in front and back of unit on/off.
RESET
Power
Standby power continues to be supplied to the system, i.e. the power supplies
and the IPMI remain energized)
HDD Release
1.5.2

Control Panel LEDs

Info (red):
Info (blue):
NIC 2,
10
Front Panel (bezel removed)
("UID"): Unit identifier button – to identify this unit, press this button (or
button: Reboot the system
button: Apply/remove power from the power supply of the server. (Note:
Lever: Pull to release one of the two hot-swap RAID hard disks.
Red blinking fast (1x/sec): Fan fail
Red blinking slowly (1x/4 sec): Power fail
Red solid: CPU overheat
Blue solid: Local UID button depressed
Blue blinking: UID has been activated via IPMI
1: Activity on GLAN 1,2 when flashing green
