6. In this panel, you can perform the following actions:
In order to apply a static IP address to any Ethernet port, DHCP must be disabled.
To update network settings using a serial connection, please see
Address via the Serial Port"
2.7.2

Setting Up an IP Address via the Serial Port

VelaSync's rear panel serial port connector is a standard DB9 male connector. Com-
munication with the serial port can be performed using a PC with a terminal emulator
program (such as PuTTY or TeraTerm), using a pinned null-modem standard DB9F to
CHAPTER 2 • VelaSync User's Manual Rev. 3
enable or disable the ethernet port
enable DHCP
disable DHCP (selecting this function will provide access to the remaining
settings)
assign a static IP address
set netmask values
set Gateway, domain, DNS, and MTU values.
Note: Wait to click
assigning values to avoid errors.
below.
2.7 Configuring IP Address(es)
Submit or Apply until fully finished
"Setting Up an IP
33
