Effect, Color

Applies color
Note:
effects cannot be applied to lights with fixed colors or a choice of single colors on wheels or scrollers.
How to Apply a Color Effect
1. Select some channels.
2. Go to Controls>Effects.
3. Press
4. Choose the color tab from the tab area.
5. Select a pattern.
6. Adjust the effect settings for the desired result.
Effect Settings
Depth- The amount that the effect deviates from the static color set on the light. When set to full, the
light follows the effect colors entirely. When set to 50%, the resulting colors will be half way between
the light's static rest-state color (the color it was before the effect was chosen), and so on.
Speed- The speed or rate that the effect runs.
Fan- The amount the effect is spread out over the selected lights. Without fan, all the lights change
together at the same time. With increasing the value of fan, the lights respond to different parts of the
effect, offset from each other.
Chroma- The intensity of color. Chroma is currently 0-255. 127 = Normal, 0 = Paler, and 255 = Sat-
urated.
Running Effect Control
When effects run, an icon is displayed in the vertical area to the right of the
any time to manipulate the effects.
Effects may be edited, removed, or reduced via the wheel control when they are playing back from
or cues.

Effect, Shape

Applies shape (motion) effects to chosen channels.
44
effects to selected channels.
The color effect system only works with lights capable of performing color mixing. Color
Add Effect.
Note:
The order in which the lights are selected will affect how they are spread-out by the
fan setting.
Note:
Effects containing fully saturated colors, such as Rainbow, cannot be made 'more' sat-
urated with the Chroma control.
stage map. This may be selected at
playbacks
