Home All
Home Position
Home ColorMix
Home Beam
Home All
Sends all or just the selected
pre-recorded in the patching personality files, and may not be changed by the user.
Generally, parameters home to useful settings. For instance, pan and tilt will be set to mid-way values. Gobos
and beam control will be set so that the beam is unobstructed and visible.
Home Position
Sends just the
recorded in the patching personality files, and may not be changed by the user.
Generally, parameters home to useful settings. For instance, pan and tilt will be set to mid-way values.
Home ColorMix
Sends just the
recorded in the patching personality files, and may not be changed by the user.
Generally, parameters home to useful settings.
Home Beam
Sends just the
recorded in the patching personality files, and may not be changed by the user.
Generally, parameters home to useful settings. Gobos and beam control will be set so that the beam is unob-
structed and visible.
Nudge
Nudge allows for fine control of
The Nudge button is available on the second page of position parameter control and on the first page of color-
mix parameter control.
Press the buttons to add or subtract from the current values. Press and hold the buttons to quickly make a jump
in value.
For position, the actual pan and tilt values will display above the Nudge button
26
parameters
position parameters
of the selected lights to their home positions. The home positions are pre-
colormix parameters
of the selected lights to their home positions. The home positions are pre-
beam parameters
of the selected lights to their home positions. The home positions are pre-
position
and
of the selected lights to their home positions. The home positions are
color
parameters.
Controlling Your Lighting System
