Installation
3 3
Figure 3.19 Control Card Wiring Path for Frame Size D13
Figure 3.20 Control Card Wiring Path for Frame Size E9
32
Instruction Manual
1 Routing path for the control card wiring, inside the adjustable

3.4.18 Access to Control Terminals

All terminals to the control cables are located beneath the
LCP (both filter and adjustable frequency drive LCP). They
are accessed by opening the door of the unit.
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
frequency drive enclosure.
Figure 3.21 Control Card Wiring Path for Frame Size F18
1
MG37A222
