Danfoss VLT AutomationDrive FC 302 Instruction Manual page 83

Programming
6.3.3 1-** Load/Motor
Par. Parameter description
No. #
1-0* General Settings
1-00 Configuration Mode
1-01 Motor Control Principle
1-02 Flux Motor Feedback Source
1-03 Torque Characteristics
1-04 Overload Mode
1-05 Local Mode Configuration
1-06 Clockwise Direction
1-07 Motor Angle Offset Adjust
1-1* Special Settings
1-10 Motor Construction
1-11 Motor Model
1-14 Damping Gain
1-15 Low Speed Filter Time Const.
1-16 High Speed Filter Time Const.
1-17 Voltage filter time const.
1-18 Min. Current at No Load
1-2* Motor Data
1-20 Motor Power [kW]
1-21 Motor Power [HP]
1-22 Motor Voltage
1-23 Motor Frequency
1-24 Motor Current
1-25 Motor Nominal Speed
1-26 Motor Cont. Rated Torque
1-29 Automatic Motor Adaptation (AMA)
1-3* Addl. Motor Data
1-30 Stator Resistance (Rs)
1-31 Rotor Resistance (Rr)
1-33 Stator Leakage Reactance (X1)
1-34 Rotor Leakage Reactance (X2)
1-35 Main Reactance (Xh)
1-36 Iron Loss Resistance (Rfe)
1-37 d-axis Inductance (Ld)
1-38 q-axis Inductance (Lq)
1-39 Motor Poles
1-40 Back EMF at 1000 RPM
1-41 Motor Angle Offset
1-44 d-axis Inductance Sat. (LdSat)
1-45 q-axis Inductance Sat. (LqSat)
1-46 Position Detection Gain
1-47 Torque Calibration
1-48 Inductance Sat. Point
1-5* Load-Indep. Setting
1-50 Motor Magnetization at Zero Speed
1-51 Min Speed Normal Magnetizing [RPM]
1-52 Min Speed Normal Magnetizing [Hz]
1-53 Model Shift Frequency
1-54 Voltage reduction in fieldweakening
1-55 U/f Characteristic - U
1-56 U/f Characteristic - F
1-58 Flystart Test Pulses Current
1-59 Flystart Test Pulses Frequency
1-6* Load-Depend. Settg.
1-60 Low Speed Load Compensation
1-61 High Speed Load Compensation
1-62 Slip Compensation
1-63 Slip Compensation Time Constant
MG37A222
Instruction Manual
Default value 4-set-up
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[1] 24V encoder All set-ups
[0] Constant torque All set-ups
[0] High torque All set-ups
[2] As mode par 1-00 All set-ups
[0] Normal All set-ups
[0] Manual All set-ups
[0] Asynchron All set-ups
ExpressionLimit All set-ups
140 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
[0] Off All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 N/A All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
100 % All set-ups
ExpressionLimit All set-ups
35 % All set-ups
100 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
0 V All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
100 % All set-ups
100 % All set-ups
ExpressionLimit All set-ups
ExpressionLimit All set-ups
Danfoss A/S © Rev. 2014-02-07 All rights reserved.
FC 302 Change Conver-
only during sion index
operation
TRUE -
FALSE -
x FALSE -
TRUE -
FALSE -
TRUE -
FALSE -
x FALSE -
FALSE -
x FALSE -
TRUE 0
TRUE -2
TRUE -2
TRUE -3
TRUE 0
FALSE 1
FALSE -2
FALSE 0
FALSE 0
FALSE -2
FALSE 67
FALSE -1
FALSE -
FALSE -4
FALSE -4
FALSE -4
FALSE -4
FALSE -4
FALSE -3
x FALSE -4
x FALSE -6
FALSE 0
x FALSE 0
FALSE 0
x FALSE -4
x FALSE -4
TRUE 0
TRUE -
x TRUE 0
TRUE 0
TRUE 67
TRUE -1
x FALSE -1
FALSE 0
TRUE -1
TRUE -1
FALSE 0
FALSE 0
TRUE 0
TRUE 0
TRUE 0
TRUE -2
Type
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
Uint8
6 6
Uint8
Uint8
Int16
Uint16
Uint16
Uint16
Uint16
Uint32
Uint32
Uint16
Uint16
Uint32
Uint16
Uint32
Uint8
Uint32
Uint32
Uint32
Uint32
Uint32
Uint32
Int32
Int32
Uint8
Uint16
Int16
Int32
Int32
Uint16
Uint8
Int16
Uint16
Uint16
Uint16
Uint16
Uint8
Uint16
Uint16
Uint16
Uint16
Int16
Int16
Int16
Uint16
81
