6.4.7 300-** AF Settings
NOTICE!
Except for 300-10 Active Filter Nominal Voltage, it is not recommended to change the settings in this parameter group
for the Low Harmonic Drive
Par. No. # Parameter description
300-0* General Settings
300-00 Harmonic cancellation mode
300-01 Compensation priority
300-08 Lagging reactive current
300-1* Network Settings
300-10 Active filter nominal voltage
300-2* CT Settings
300-20 CT primary rating
300-24 CT Sequence
300-25 CT Polarity
300-26 CT Placement
300-27 Number of CTs per phase
300-29 Start auto CT detection
300-3* Compensation
300-30 Compensation points
300-35 Cosphi reference
300-4* Paralleling
300-40 Master follower selection
300-41 Follower ID
300-42 Num. of follower AFs
300-5* Sleep Mode
300-50 Enable sleep mode
300-51 Sleep mode trig source
300-52 Sleep mode wake up trigger
300-53 Sleep mode sleep trigger
MG37A222
Instruction Manual
Default value
[0] Overall
[0] Harmonics
[0] Disabled
ExpressionLimit
ExpressionLimit
[0] L1, L2, L3
[0] Normal
[1] Load Current
1
[0] Off
0.0 A
0.500 N/A
[2] Not Paralleled
1 N/A
1 N/A
null
[0] Mains current
ExpressionLimit
80 %
